PARTS > DECKS MANUALS > 2006-03-01, 5000-18 European > 48RE Carrier Frame Assemby:

Diagram #	Part #	Description	Price	Add to Cart
1	5975-3	Cable Tie 50x7	$0.36	Add to Cart
2	5744-1	Spring Clip Bracket	$15.81	Add to Cart
3	5743-1	Spring Cover	$13.40	Add to Cart
4	5743-3	Eye Bolt 3816x2	$8.78	Add to Cart
5	5830-3	Grease Fitting 45 Deg	$4.04	Add to Cart
6	8667-10	Pivot Mount, LH/Adj.
7	8667-20	Pivot Mount, RH/Adj.
8	5743-6	Ext Spring 112x734 Green Spring	$21.11	Add to Cart
9	8674-11	Lever Deck LockLH	$14.86	Add to Cart
10	7406-1	Handle GripRed	$3.02	Add to Cart
11	8669-5	DGHS48R Lift Handle	$23.61	Add to Cart
12	5748-10	Rubber Mat 112x6	$4.25	Add to Cart
13	5740-2	Deck Pin Bushing 58	$3.36	Add to Cart
14	8661-5	48RE Carrier Frame (Less Pivots) (Includes Item # 12)
	8661-4	48RE Carrier Frame W/Forks (Less Pivots) (Includes Items # 12, 21-23, 25, F055, F068 & F098)
15	8674-10	Lever Deck LockRH	$14.86	Add to Cart
16	5830	Grease Fitting 1428	$2.47	Add to Cart
17	5714-7	NR Bearing Cap	$7.16	Add to Cart
18	5714-5	NRBearing 5715357154	$26.64	Add to Cart
19	5715-4	SU5715 13 5714 6 NR Cst Whel Pneu 8x3 00 4	$61.28	Add to Cart
	5715-10	Tire Pneu 8x3 00 4	$33.65	Add to Cart
	5715-9	Tire Tube Pneumatic 2802504	$25.70	Add to Cart
	5715-3	SU5715 14 5714 6 NR Caster Wheel Tire No Flat 8x3 00 4	$70.50	Add to Cart
	5715-11	SU5715 16 NR Tire Caster Wheel No Flat 8x3 00 4	$45.72	Add to Cart
20	5714-3	Axle Spacer Tube	$12.73	Add to Cart
21	5770-1	Caster Wheel Fork02	$57.41	Add to Cart
22	8768-1	Seal 134x118	$6.70	Add to Cart
23	8037	Bearing Cone 34ID	$12.09	Add to Cart
24	8769-1	Bearing Cup134x1716	$7.72	Add to Cart
25	8769-9	Dust Cap Deck Caster	$5.60	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F047	3816x412 Hex Bolt	$3.12	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F068	18x1 Cotter Pin	$0.18	Add to Cart
	F084	516 Wave Spring Washer	$1.58	Add to Cart
	F098	5818 Slotted Hex Nut	$3.50	Add to Cart
	F117	Retainer Ringfor 57436	$0.58	Add to Cart
	F123	1 External Snap Ring	$1.27	Add to Cart
	F166	Retainer Ring	$0.18	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F317	316x1 Split Spring Pin	$0.50	Add to Cart
	F335	3816x78 Set ScrewSS	$2.71	Add to Cart
	F336	3816 Jam Nut	$0.34	Add to Cart
