Part Lookup Tool
PARTS > ADDITIONAL MANUALS > 2007-10-01, PTO Gearboxes > 6050 Tee Gearbox:
| Diagram # | Part # | Description | Price | Add to Cart |
| 1 | P018 772067 | Right Hand Cover | |
| | 2 | N/A 770111 | ?T? Drive Housing | |
| | 3 | P031 778210 | Miter Gear | |
| | 4 | P003 778101A | Miter Gear | |
| | 5 | P008 792025 | Screw, 10-24 x 1/2" | |
| | 6 | P046 780176 | Load Ring | |
| | 7 | P032 788018 | Snap Ring | |
| | 8 | P052 788080 | Snap Ring | |
| | 9 | P051 788079 | Snap Ring | |
| | 10 | P045 780175 | Shim Washer | |
| | 11 | P048 776330 | Input Shaft (8-3/4 ") | |
| | 12 | P049 776329 | Output Shaft (6-3/64") | |
| | 13 | P041 28534 | Pipe Plug, 1/8-27 | |
| | 14 | P021 788031 | Oil Seal 7/8" | |
| | 15 | P042 788099 | Oil Seal 7/8" | |
| | 16 | P044 780174 | Ball Bearing | |
| | 17 | P043 780173 | Bearing & Cup Assy. | |
| | 18 | P050 786154 | Retainer Cap & Seal Assy. | |
| | 19 | N/A 792143 | Screw, 1/4-20 x 1-1/8" | |
| | 20 | P004 788028 | Cover Gasket | |
| | 21 | P007 788030B | Cap Gasket | |
|
