PARTS > MT MANUALS > 1997-05-22, 8000-2, Serial 21329-37479 > 9.5 Bushel Catcher Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	7584	Reinforcing Strap 100	$24.20	Add to Cart
2	8510-1	9.5 Bushel Catcher, Including Door
	8502-1	9.5 CatcherAssembly, Without Powerfil? (Includes Door)
	8502-2	9.5 CatcherAssembly (Includes Powerfil?)**
	8502-5	9.5 Catcher Assembly (Includes Frame & Powerfil?) (Priorto S/N 97-31199)
	8502-7	9.5 Catcher Assembly (Includes Frame & Powerfil?) (S/N 97-31199 and on)
3	7532	Handle, Catcher Lift
4	5583	Handle	$11.81	Add to Cart
5	8514	Door Frame, Catcher (9.5)
6	8516	NR 95 Side Strap Door	$12.00	Add to Cart
7	5588	Rubber Bumper 75x50	$5.94	Add to Cart
8	7514-1	NR Backup PlateCatcher Door	$16.26	Add to Cart
9	5587	Extension Spring (3/4 x 6-1/2)
10	5522-1	NR Hinge Backup PlateLH	$8.35	Add to Cart
11	5524	Hinge Bearing
12	8513-2	NR 95 Mnt Frame Dblr9800	$32.96	Add to Cart
13	5523	Spring Hook
14	8503	NR 95 Mounting Frame 9800	$124.01	Add to Cart
15	5522-2	NR Hinge Backup PlateRH	$8.35	Add to Cart
16	5577	Side Clip Chute Mount	$4.28	Add to Cart
17	8511-1	Delivery Chute WClips	$58.59	Add to Cart
18	5578	Rear Clip Chute Mount	$3.96	Add to Cart
19	7508	NR Safety Latch Kit7095	$56.78	Add to Cart
20	8117	Wire Harness Channel	$9.31	Add to Cart
21	5976	Grommet 38x1116	$1.08	Add to Cart
22	7533	NR Backing Plate Handle	$4.63	Add to Cart
23	8950	NR 95100 Wire Harness	$23.47	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F027	1024x58 PPHMS	$0.18	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F037	1024x58 PTH Screw	$0.18	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F079	66AAD Alum Pop Rivet 316 Diax 38 Grip	$0.65	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F129	1024x12 PTHMS	$0.34	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F195	1420x34 PPHMSSS	$1.18	Add to Cart
	F196	1420x1 PPHMSSS	$1.66	Add to Cart
	F198	250x625x040 WasherSS	$0.79	Add to Cart
	F203	1420x58 PPHMSSS	$1.30	Add to Cart
	F230	1420x114 PPHMSSS	$1.87	Add to Cart
	F242	1420x78 PPHMS SS	$1.30	Add to Cart
	F252	1024x34 PFHMS	$0.18	Add to Cart
	F255	51618x112 Hex Bolt	$1.06	Add to Cart
	F329	200IDx1939OD Washer Zinc118THK	$7.82	Add to Cart
	F330	316Dx2132L RivetSS STST68D	$2.06	Add to Cart
	F333	1420x34 PTHMS	$0.22	Add to Cart
