PARTS > MT MANUALS > 2000-03-29, 8000-4, Serial 37480-54650 > 9.5 Bushel Catcher Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	7584	Reinforcing Strap 100	$24.20	Add to Cart
2	8510-1	9.5 Bushel Catcher, Including Door
	8502-1	9.5 Catcher Assembly, Without Powerfil? (Includes Door)
	8502-2	9.5 Catcher Assembly (Includes Powerfil?)
	8502-4	9.5 Catcher Assembly (Includes Frame & Powerfil?)
3	5583	Handle	$11.81	Add to Cart
4	8514-10	95 Door Frame9800	$124.11	Add to Cart
5	8516	NR 95 Side Strap Door	$12.00	Add to Cart
6	5155-12	516 Ball Stud	$3.00	Add to Cart
7	5588	Rubber Bumper 75x50	$5.94	Add to Cart
8	7514-1	NR Backup PlateCatcher Door	$16.26	Add to Cart
9	5147	Spring Clip	$1.02	Add to Cart
10	5155	Gas Spg AssyCatcher Door	$47.06	Add to Cart
11	5522-1	NR Hinge Backup PlateLH	$8.35	Add to Cart
12	5524-1	NR Flanged Hinge Bearing	$8.80	Add to Cart
13	5523-6	Gas Spring Plate	$3.12	Add to Cart
14	5155-13	10mm Ball Stud 51618 34 Thread	$3.19	Add to Cart
15	5155-15	Box Support Gas Spring	$7.61	Add to Cart
16	7533	NR Backing Plate Handle	$4.63	Add to Cart
17	7532	Handle, Catcher Lift
18	8117	Wire Harness Channel	$9.31	Add to Cart
19	5976	Grommet 38x1116	$1.08	Add to Cart
20	5522-2	NR Hinge Backup PlateRH	$8.35	Add to Cart
21	7508	NR Safety Latch Kit7095	$56.78	Add to Cart
22	8503	NR 95 Mounting Frame 9800	$124.01	Add to Cart
23	5281-5	Clevis Pin 14x080	$1.37	Add to Cart
24	8513-2	NR 95 Mnt Frame Dblr9800	$32.96	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F027	1024x58 PPHMS	$0.18	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F037	1024x58 PTH Screw	$0.18	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F079	66AAD Alum Pop Rivet 316 Diax 38 Grip	$0.65	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F129	1024x12 PTHMS	$0.34	Add to Cart
	F172	1420x34 Carriage Bolt	$0.50	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F195	1420x34 PPHMSSS	$1.18	Add to Cart
	F196	1420x1 PPHMSSS	$1.66	Add to Cart
	F198	250x625x040 WasherSS	$0.79	Add to Cart
	F203	1420x58 PPHMSSS	$1.30	Add to Cart
	F230	1420x114 PPHMSSS	$1.87	Add to Cart
	F242	1420x78 PPHMS SS	$1.30	Add to Cart
	F252	1024x34 PFHMS	$0.18	Add to Cart
	F255	51618x112 Hex Bolt	$1.06	Add to Cart
	F329	200IDx1939OD Washer Zinc118THK	$7.82	Add to Cart
	F330	316Dx2132L RivetSS STST68D	$2.06	Add to Cart
	F351	Aluminum Pop Rivet	$0.94	Add to Cart
