PARTS > MS MANUALS > 1991-07-01, 5895-1, Serial 00000-20380 > Body Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5100-4	Welded Body Assembly (87 & On)
2	5103	NR Seat	$250.95	Add to Cart
3	5112	Rear Bumper	$46.71	Add to Cart
4	5650	Utility Bed SCSNGL	$303.03	Add to Cart
5	5170-3	FSC Lever Assembly (89 & On C Only)
	5170-2	NR FSC Lever	$70.14	Add to Cart
6	5450-2	OBSteering LeverRH Tech Services	$48.73	Add to Cart
7	5451-2	OB Steering LeverLH Tech Services	$48.73	Add to Cart
8	5145	NR Gas Spring Assembly	$54.22	Add to Cart
	5145-1	Gas Spring Retrofit Kit (85 Model)
9	5146	10mm Ball Stud	$3.77	Add to Cart
10	5147	Spring Clip	$1.02	Add to Cart
11	5108	NR Thrttle Cntrl CableBS	$20.77	Add to Cart
12	5109	NR Choke Cntrl CableBS	$24.29	Add to Cart
13	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
14	5223	Ext Spring 14x512	$6.00	Add to Cart
15	5850	Handle Grip Foam	$5.52	Add to Cart
16	5180	Edge MoldingLvr Opening	$3.43	Add to Cart
17	5990	Hourmeter (Optional Standard Model)
18	5863	Panel Plug (2-1/16)**
19	5991-1	Hourmeter Power Lead Wire	$6.26	Add to Cart
20	5991-2	Hourmeter Ground Wire	$5.83	Add to Cart
21	5833	Cable Clamp 14	$1.30	Add to Cart
22	5870	Tee Control Knob Throttle Choke	$2.06	Add to Cart
23	5960	Ignition Switch (Incl. Hardware)
24	5960-2	Ignition Key (1 Set)	$5.11	Add to Cart
25	5960-3	Key Tip Protector	$0.34	Add to Cart
26	5960-4	Ign. Switch Panel Nut (Incl. with 5960)
27	5830	Grease Fitting 1428	$2.47	Add to Cart
28	5862	NR FSC Knob	$9.56	Add to Cart
29	5955	Seat Switch
30	5153-2	Cover Plate (87 & On)*
31	5802-1	NR Decal FenderRHLexan	$7.80	Add to Cart
32	5802-2	NR Decal FenderLHLexan	$9.79	Add to Cart
33	5805	NR Decal Engine Exhaust	$2.45	Add to Cart
34	5815	NR Decal Body LiftLexan	$11.42	Add to Cart
35	5806	NR Decal Blade Clutch	$2.62	Add to Cart
36	5804	Decal, Blower Blade Warning***
37	5856	NR Decal Made In USA	$1.30	Add to Cart
38	5803	(NR) Decal- Walker Mfg./Lexan	$5.66	Add to Cart
39	5101	Spring Bracket (Retrofit 80-85, Bolt On)
40	5162	Roller Wheel 5 Rubber	$13.40	Add to Cart
41	5161	NR Bumper Pad	$5.78	Add to Cart
42	5989	Light Kit (Optional)
43	5989-1	Light
44	5995	Toggle Switch OffOn	$14.16	Add to Cart
45	5995-1	Wire Terminal Adapter	$2.52	Add to Cart
46	5995-2	Switch Boot	$5.26	Add to Cart
47	5995-3	Power Lead Wire Lights	$7.94	Add to Cart
48	5838	Decal, Gates Belt Usage**
49	5800	NR Decal Walker MowerLexan 4 Round	$9.44	Add to Cart
50	5651	RH Utility Bed Mount
51	5652	LH Utility Bed Mount
52	5588	Rubber Bumper 75x50	$5.94	Add to Cart
53	5885	Armrest Kit Std Seat	$131.46	Add to Cart
54	5886-1	ArmrestRH Std	$54.36	Add to Cart
55	5886-2	ArmrestLH Std	$54.36	Add to Cart
56	5887	Mounting Bracket	$42.74	Add to Cart
57	5888	NR Armrest Hardware Kit	$16.19	Add to Cart
F002	F002	1024 Keps Nut	$0.18	Add to Cart
F004	F004	1420 Keps Nut	$0.34	Add to Cart
F005	F005	1420 ESNA Nut	$0.34	Add to Cart
F009	F009	51618 Whiz Locknut	$0.50	Add to Cart
F014	F014	3816 ESNA Nut	$0.65	Add to Cart
F020	F020	51618 ESNA Nut	$0.34	Add to Cart
F025	F025	1024x38 PPHMS	$0.18	Add to Cart
F032	F032	1420x34 Hex Bolt	$0.50	Add to Cart
F033	F033	1420x1 PTH Bolt	$0.36	Add to Cart
F034	F034	51618x34 Hex Bolt	$0.79	Add to Cart
F040	F040	3816x112 Hex Bolt	$1.54	Add to Cart
F049	F049	516 SAE Washer	$0.18	Add to Cart
F050	F050	14 SAE Washer	$0.18	Add to Cart
F051	F051	38 SAE Washer	$0.65	Add to Cart
F059	F059	38 Wave Spring Washer	$1.32	Add to Cart
F060	F060	AN960516 Washer	$0.29	Add to Cart
F083	F083	AA68D Aluminum Pop Rivet 316Dx2132L	$0.43	Add to Cart
F084	F084	516 Wave Spring Washer	$1.58	Add to Cart
F087	F087	10x78 Fender Washer	$0.65	Add to Cart
F091	F091	51618x58 Hex Bolt	$0.65	Add to Cart
F104	F104	1420x34 PFH Bolt	$0.22	Add to Cart
F112	F112	58x114x03 Washer	$1.32	Add to Cart
F154	F154	58 Int Star Lock Washer	$1.15	Add to Cart
