PARTS > DECKS MANUALS > 2018-09-21, 5000-45 > DC36R Deck Assembly:
| Diagram # | Part # | Description | Price | Add to Cart |
| 1 | 8618-1 | Cover PTO Shaft Guard | $21.27 |
Add to Cart | | 2 | 8619 | PTO Shaft Guard | $19.57 |
Add to Cart | | 8618 | SU8618 10 PTO Shaft Guard Assembly | $40.91 |
Add to Cart | | 3 | 5285-5 | UJoint Shaft90 Spline Keyed | $290.01 |
Add to Cart | | 90 | Degree, Spline, Keyed (Includes Items # F065, F076 & F318) | |
| | 4 | 6704-7 | DC36R Gearbox Tube Assembly Woodruff Key | $1,426.00 |
Add to Cart | | 5 | 6711-1 | HD Gearbox and Tube Assembly (Includes Items # 6-8, 17-20, 23, 25, | |
| | 6 | 5053-9 | HD Gearbox 112 CWCW | $469.56 |
Add to Cart | | 7 | 5051-5 | HD Tee Gearbox 11 CWCWCCW | $516.39 |
Add to Cart | | 8 | 5052-9 | HD Gearbox 112 CCWCCW | $468.72 |
Add to Cart | | 9 | 5794 | NR Dischg Chute WO Spg Mnt 612 Dia | $83.58 |
Add to Cart | | 5794-1 | Discharge Chute WSpg Mnt | $112.35 |
Add to Cart | | 10 | 8678 | Spring Mount Chute | $10.13 |
Add to Cart | | 11 | 8677 | Extension Spring 1x6116 | $11.99 |
Add to Cart | | 12 | 5726 | Chute Hinge 2x8 | $7.75 |
Add to Cart | | 13 | 5755-2 | Chute LipTop | $5.33 |
Add to Cart | | 14 | 5755-3 | Chute LipBottom | $5.33 |
Add to Cart | | 15 | 8678-4 | Spring Mount, Chute | |
| | 16 | 5794-3 | Discharge Chute WSpring Mnt | $97.92 |
Add to Cart | | 17 | 6054 | Spline Coupling | $12.09 |
Add to Cart | | 18 | P007 | Gasket Cap P788030 | $2.70 |
Add to Cart | | 19 | 5065 | Conn Tube 7 11 16 | $52.98 |
Add to Cart | | 20 | 6733-4 | Connecting Shaft5516 | $42.94 |
Add to Cart | | 21 | 5052-11 | Blade Drive GearboxLH 112 | $309.54 |
Add to Cart | | 22 | 5706-4 | Seal Protector Plate | $4.81 |
Add to Cart | | 23 | 5704-1 | Gearbox Cover Support | $9.55 |
Add to Cart | | 24 | 5051-2 | Tee GearboxKeyed 78 Dia Shaft | $284.55 |
Add to Cart | | 25 | 5060 | Connector Tube 2 5 16 | $48.73 |
Add to Cart | | 26 | 5052-3 | 1375x750x187 Washer | $3.84 |
Add to Cart | | 27 | 5747-11 | Rubber Mat 3x6 | $7.64 |
Add to Cart | | 28 | 5746-6 | 36 Gearbox Cover | $70.52 |
Add to Cart | | 29 | 8670 | TiltUp Hook | $34.85 |
Add to Cart | | 30 | 5162-12 | Roller Wheel 5Poly | $17.37 |
Add to Cart | | 31 | 5710-6 | DC36R Deck Housing | $1,088.00 |
Add to Cart | | 32 | NS | Deck Serial Number Plate | |
| | 33 | 5705-36 | Blade 19RH Rotation | $27.06 |
Add to Cart | | 34 | 5705-35 | Blade 19LH Rotation | $27.06 |
Add to Cart | | 35 | 5706 | Blade Hub Trash Guard | $37.05 |
Add to Cart | | 36 | 8735-10 | Rubber Mat 5x6 | $8.35 |
Add to Cart | | 37 | 7775-1 | Hitch PinLH Silver 6 | $4.82 |
Add to Cart | | 38 | 8788-1 | Rubber Mat 1x2 | $2.16 |
Add to Cart | | 39 | 7775-2 | Hitch PinRH Gold 6 | $5.08 |
Add to Cart | | 40 | 7434-1 | Washer 138x5812 Thick Rubber | $2.95 |
Add to Cart | | 41 | 5727-1 | Washer Shim 58ID | $4.25 |
Add to Cart | | F002 | 1024 Keps Nut | $0.18 |
Add to Cart | | F004 | 1420 Keps Nut | $0.34 |
Add to Cart | | F005 | 1420 ESNA Nut | $0.34 |
Add to Cart | | F013 | 3816 Whiz Locknut | $0.65 |
Add to Cart | | F018 | 5818 Hex Nut | $1.66 |
Add to Cart | | F025 | 1024x38 PPHMS | $0.18 |
Add to Cart | | F029 | 1420x12 Hex Bolt | $0.50 |
Add to Cart | | F038 | 3816x1 Hex Bolt | $1.06 |
Add to Cart | | F039 | 3816x114 Hex Bolt | $1.42 |
Add to Cart | | F050 | 14 SAE Washer | $0.18 |
Add to Cart | | F055 | 58 SAE Washer | $0.65 |
Add to Cart | | F056 | 58 Split Lock Washer | $0.65 |
Add to Cart | | F059 | 38 Wave Spring Washer | $1.32 |
Add to Cart | | F065 | 316x34 Woodruff Key 606 | $2.18 |
Add to Cart | | F076 | 3816x58 SQH Set Screw | $0.65 |
Add to Cart | | F087 | 10x78 Fender Washer | $0.65 |
Add to Cart | | F124 | 1032x38 Taptite MS | $0.36 |
Add to Cart | | F129 | 1024x12 PTHMS | $0.34 |
Add to Cart | | F136 | AN960C416L Washer | $0.29 |
Add to Cart | | F179 | 1420x1 Hex Bolt | $0.65 |
Add to Cart | | F202 | 1024x58 SHC Screw GR5 | $1.06 |
Add to Cart | | F206 | 2x316 Drive Pin | $0.18 |
Add to Cart | | F211 | 1420x78 Hex Bolt | $0.65 |
Add to Cart | | F246 | 1420x12 PTHMS | $0.34 |
Add to Cart | | F278 | 38 Split Lock Washer | $0.18 |
Add to Cart | | F318 | 3816x34 SQH Set Screw | $0.74 |
Add to Cart | | F403 | 1420x12 PTHMS SS | $1.18 |
Add to Cart | | F426 | 1420x12 Carriage Bolt | $0.50 |
Add to Cart | | F462 | 316x468 010 SemiTube Rivet | $0.34 |
Add to Cart | | F517 | Washer 38x118x18 | $1.58 |
Add to Cart | | F543 | SU8490 3816x112 BH Cap Screw | $4.99 |
Add to Cart |
