Part Lookup Tool

PARTS > DECKS MANUALS > 2024-10-16, 5000-88 > DC42V-2 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8620-3	Hinge PTO Shaft Guard	$10.49	Add to Cart
2	8618-1	Cover PTO Shaft Guard	$21.27	Add to Cart
3	8617-1	42E PTO Shaft Guard	$20.10	Add to Cart
	8616-1	NR 42E PTO Shaft Guard Assy	$51.13	Add to Cart
4	5285-5	UJoint Shaft90 Spline Keyed	$290.01	Add to Cart
5	6711-6	DC42V Gearbox Tube Assembly HD ProGear	$1,811.00	Add to Cart
6	8497-1	NR Discharge Chute CSSW	$126.32	Add to Cart
	8494	4248E Dschrge Chute WSpring Mnt 525x825	$129.26	Add to Cart
7	8489	4248E Spring MountChute	$7.99	Add to Cart
8	8677	Extension Spring 1x6116	$11.99	Add to Cart
9	8488	Chute Hinge 2x8	$9.12	Add to Cart
10	8494-1	Protector Plate	$31.83	Add to Cart
11	6054	Spline Coupling	$12.09	Add to Cart
12	5068-6	ORing 178x2	$0.80	Add to Cart
13	5066-2	Connector Tube 9343 ORing	$56.22	Add to Cart
14	6733-6	Connecting Shaft 7	$38.57	Add to Cart
15	5052-14	HD Bld Dr Gearbox 11CCWCCW	$446.67	Add to Cart
16	5704-1	Gearbox Cover Support	$9.55	Add to Cart
17	5051-5	HD Tee Gearbox 11 CWCWCCW	$516.39	Add to Cart
18	6732-8	42E Cnnctng Shft 1516	$22.75	Add to Cart
19	5068-5	42E Connector Tube 3718 Oring	$58.59	Add to Cart
20	5053-14	HD Bld Dr Gearbox 11 CWCW	$494.34	Add to Cart
21	5589-1	1420x112 Stud Threadlocker	$2.15	Add to Cart
22	5747-11	Rubber Mat 3x6	$7.64	Add to Cart
23	8629-1	42E Gearbox Cover02	$39.62	Add to Cart
24	8670	TiltUp Hook	$34.85	Add to Cart
25	5162-12	Roller Wheel 5Poly	$17.37	Add to Cart
26	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
27	NS	Deck Serial
28	5705-3	Blade 22RH Rotation	$35.60	Add to Cart
29	5706	Blade Hub Trash Guard	$37.05	Add to Cart
30	5705-4	Blade 22LH Rotation	$35.60	Add to Cart
	5705-8	42GHS Blade Set WHubs	$140.07	Add to Cart
31	5747-10	Rubber Mat NoHole 3x6	$5.10	Add to Cart
32	7775-1	Hitch PinLH Silver 6	$4.82	Add to Cart
33	8788-1	Rubber Mat 1x2	$2.16	Add to Cart
34	8481	42EGHS Deck Housing	$1,386.00	Add to Cart
35	7775-2	Hitch PinRH Gold 6	$5.08	Add to Cart
36	7434-1	Washer 138x5812 Thick Rubber	$2.95	Add to Cart
37	5727-1	Washer Shim 58ID	$4.25	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F036	1420x12 SBH Screw	$0.43	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F087	10x78 Fender Washer	$0.65	Add to Cart
	F129	1024x12 PTHMS	$0.34	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F223	316x516 SemiTube Rivet	$0.44	Add to Cart
	F246	1420x12 PTHMS	$0.34	Add to Cart
	F278	38 Split Lock Washer	$0.18	Add to Cart
	F318	3816x34 SQH Set Screw	$0.74	Add to Cart
	F403	1420x12 PTHMS SS	$1.18	Add to Cart
	F462	316x468 010 SemiTube Rivet	$0.34	Add to Cart
	F517	Washer 38x118x18	$1.58	Add to Cart
	F568	1024 Flange Top Lock Nut	$1.56	Add to Cart
