PARTS > DECKS MANUALS > 2014-06-18, 5000-21 European > DC48RV-2 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8620-3	Hinge PTO Shaft Guard	$10.49	Add to Cart
2	8618-1	Cover PTO Shaft Guard	$21.27	Add to Cart
3	8619	PTO Shaft Guard	$19.57	Add to Cart
	8618	SU8618 10 PTO Shaft Guard Assembly	$40.91	Add to Cart
4	7285-5	UJoint ShaftSplined Keyed	$313.32	Add to Cart
5	7275-16	UJnt Tube AssySpline 10 OAL	$217.77	Add to Cart
6	6704-45	Gearbox and Tube Assembly, Keyed (Includes Items # 13-21, F124, F136, F179 & F211)
7	5794	NR Dischg Chute WO Spg Mnt 612 Dia	$83.58	Add to Cart
	5794-1	Discharge Chute WSpg Mnt	$112.35	Add to Cart
8	8678	Spring Mount Chute	$10.13	Add to Cart
9	8677	Extension Spring 1x6116	$11.99	Add to Cart
10	5726	Chute Hinge 2x8	$7.75	Add to Cart
11	5755-2	Chute LipTop	$5.33	Add to Cart
12	5755-3	Chute LipBottom	$5.33	Add to Cart
13	6054	Spline Coupling	$12.09	Add to Cart
14	P007	Gasket Cap P788030	$2.70	Add to Cart
15	5066	Connector Tube 9 5 16	$49.21	Add to Cart
16	6733-6	Connecting Shaft 7	$38.57	Add to Cart
17	5052-5	(NR) Gearbox- HD (LH Rotation)	$243.69	Add to Cart
18	5704-1	Gearbox Cover Support	$9.55	Add to Cart
19	7751-14	(NR)Ext Tee Grbx- Keyed (1.2:1 ) HD	$256.28	Add to Cart
20	6733-2	Connecting Shaft 418	$41.27	Add to Cart
21	5061	Connector Tube 6 11 16	$44.21	Add to Cart
22	5747-12	Rubber Mat 3x6	$6.74	Add to Cart
23	7785-3	NR 48 Gearbox Cover02	$74.03	Add to Cart
24	8670-9	Tilt Up Hook	$33.15	Add to Cart
25	5162-11	"Roller Wheel (5""Poly)"	$9.05	Add to Cart
26	NS	Deck Serial Number Plate
27	7705-2	Blade 25LH Rotation	$37.09	Add to Cart
	7705-3	48GHS Blade Set WHubs	$143.96	Add to Cart
28	5706	Blade Hub Trash Guard	$37.05	Add to Cart
29	7705-1	Blade 25 RH Rotation	$37.09	Add to Cart
30	7775-1	Hitch PinLH Silver 6	$4.82	Add to Cart
31	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
32	8788-1	Rubber Mat 1x2	$2.16	Add to Cart
33	7702-4	DGHS48RE Deck Housing	$1,359.03	Add to Cart
34	7775-2	Hitch PinRH Gold 6	$5.08	Add to Cart
35	7434-1	Washer 138x5812 Thick Rubber	$2.95	Add to Cart
36	5727-1	Washer Shim 58ID	$4.25	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F036	1420x12 SBH Screw	$0.43	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F087	10x78 Fender Washer	$0.65	Add to Cart
	F129	1024x12 PTHMS	$0.34	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F179	1420x1 Hex Bolt	$0.65	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F246	1420x12 PTHMS	$0.34	Add to Cart
	F278	38 Split Lock Washer	$0.18	Add to Cart
	F318	3816x34 SQH Set Screw	$0.74	Add to Cart
	F403	1420x12 PTHMS SS	$1.18	Add to Cart
	F462	316x468 010 SemiTube Rivet	$0.34	Add to Cart
	F517	Washer 38x118x18	$1.58	Add to Cart
	F543	SU8490 3816x112 BH Cap Screw	$4.99	Add to Cart
