PARTS > DECKS MANUALS > 2014-06-18, 5000-21 European > DC52RV-2 Carrier Frame Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5975-3	Cable Tie 50x7	$0.36	Add to Cart
2	5744-1	Spring Clip Bracket	$15.81	Add to Cart
3	5743-1	Spring Cover	$13.40	Add to Cart
4	5743-3	Eye Bolt 3816x2	$8.78	Add to Cart
5	5830	Grease Fitting 1428	$2.47	Add to Cart
6	8667-3	Pivot Mount LHADJ	$70.46	Add to Cart
7	8667-4	Pivot Mount RHADJ	$82.07	Add to Cart
8	5743-6	Ext Spring 112x734 Green Spring	$21.11	Add to Cart
9	8674-11	Lever Deck LockLH	$14.86	Add to Cart
10	7406-1	Handle GripRed	$3.02	Add to Cart
11	8669-4	52GHS Lift Handle	$49.15	Add to Cart
12	5740-2	Deck Pin Bushing 58	$3.36	Add to Cart
13	8811-3	52GHS Carrier Frame	$638.61	Add to Cart
	8811-2	NRDC52 Carrier Frame WForks	$742.14	Add to Cart
14	8674-10	Lever Deck LockRH	$14.86	Add to Cart
15	5714-8	Bearing	$12.36	Add to Cart
16	5714-9	NR Spacer Tube	$16.37	Add to Cart
17	5715-14	Caster Wheel No Flat 8x3 00 4 Without Axle Spacer Tube	$63.21	Add to Cart
	5715-16	Caster Wheel TireNo Flat 8x 3004	$51.26	Add to Cart
	5715-13	Caster Wheel Pnue 8x3 00 4 Without Axle Spacer Tube	$65.54	Add to Cart
	5715-10	Tire Pneu 8x3 00 4	$33.65	Add to Cart
	5715-9	Tire Tube Pneumatic 2802504	$25.70	Add to Cart
18	5714-6	Axle Spacer Tube	$13.84	Add to Cart
19	5770-1	Caster Wheel Fork02	$57.41	Add to Cart
20	8768-1	Seal 134x118	$6.70	Add to Cart
21	8037	Bearing Cone 34ID	$12.09	Add to Cart
22	8769-1	Bearing Cup134x1716	$7.72	Add to Cart
23	8769-9	Dust Cap Deck Caster	$5.60	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F047	3816x412 Hex Bolt	$3.12	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F068	18x1 Cotter Pin	$0.18	Add to Cart
	F084	516 Wave Spring Washer	$1.58	Add to Cart
	F098	5818 Slotted Hex Nut	$3.50	Add to Cart
	F117	Retainer Ringfor 57436	$0.58	Add to Cart
	F123	1 External Snap Ring	$1.27	Add to Cart
	F166	Retainer Ring	$0.18	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F317	316x1 Split Spring Pin	$0.50	Add to Cart
	F335	3816x78 Set ScrewSS	$2.71	Add to Cart
	F336	3816 Jam Nut	$0.34	Add to Cart
	F353	3816 ESNA LP Nut	$0.50	Add to Cart
	F489	Washer 14x78x090	$2.18	Add to Cart
	F520	1428x38 Hex Bolt	$1.54	Add to Cart
