PARTS > DECKS MANUALS > 1998-07-24, 5000-6 > DGHS48 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8618-1	Cover PTO Shaft Guard	$21.27	Add to Cart
2	8619	PTO Shaft Guard	$19.57	Add to Cart
	8618	SU8618 10 PTO Shaft Guard Assembly	$40.91	Add to Cart
3	7275-15	UJnt TubeSplineNT 925 OAL	$223.44	Add to Cart
4	7285-15	UJnt Shaft90degSpline	$334.74	Add to Cart
5	8067-10	Shr Pin WCotter Set5	$11.89	Add to Cart
6	5830	Grease Fitting 1428	$2.47	Add to Cart
7	6054	Spline Coupling	$12.09	Add to Cart
8	5052-1	Gearbox LH Rotation	$280.77	Add to Cart
9	5706-4	Seal Protector Plate	$4.81	Add to Cart
10	6732-6	Connecting Shaft (7?)
11	P007	Gasket Cap P788030	$2.70	Add to Cart
12	5066	Connector Tube 9 5 16	$49.21	Add to Cart
13	8677	Extension Spring 1x6116	$11.99	Add to Cart
14	8678	Spring Mount Chute	$10.13	Add to Cart
15	7798	Discharge Chute (3-1/2 x 11-1/2)
	7794	48GHS Dschrg Chte WO Spg	$110.25	Add to Cart
16	7726	Chute Hinge 2x11	$15.51	Add to Cart
17	7755	Chute Lower Lip
18	5162-11	"Roller Wheel (5""Poly)"	$9.05	Add to Cart
19	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
20	7705-1	Blade 25 RH Rotation	$37.09	Add to Cart
21	5706	Blade Hub Trash Guard	$37.05	Add to Cart
22	7705-2	Blade 25LH Rotation	$37.09	Add to Cart
	7705-3	48GHS Blade Set WHubs	$143.96	Add to Cart
23	5747-6	Safety Tread (6 x 18-1/8)
24	7701	NR 48GHS Deck Housing	$843.89	Add to Cart
25	5775-2	Hitch Pin 6	$3.24	Add to Cart
26	NS	Deck Serial Number Plate
27	8670	TiltUp Hook	$34.85	Add to Cart
28	7751-15	Tee Gearbox Shear 1 2 1 W Flange	$333.98	Add to Cart
29	6732-2	Connecting Shaft (4-1/8)
30	5061	Connector Tube 6 11 16	$44.21	Add to Cart
31	5052-3	1375x750x187 Washer	$3.84	Add to Cart
32	5747-0	Safety Tread (3 x 6)
33	7785	NR 48 Gearbox Cover9302	$72.41	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F036	1420x12 SBH Screw	$0.43	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F079	66AAD Alum Pop Rivet 316 Diax 38 Grip	$0.65	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F087	10x78 Fender Washer	$0.65	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F129	1024x12 PTHMS	$0.34	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F229	CClip 1316	$0.50	Add to Cart
	F246	1420x12 PTHMS	$0.34	Add to Cart
	F295	316x112 Split Spg Pin	$0.64	Add to Cart
