Part Lookup Tool

PARTS > DECKS MANUALS > 1997-07-31, 5000-5 > DGHS48 Deck Assembly (Non-Tilt):

Diagram #	Part #	Description	Price	Add to Cart
1	7745	PTO Shaft Guard
2	7285	Universal Joint Shaft Assembly (Includes Item # F076)
3	6054	Spline Coupling	$12.09	Add to Cart
4	5052-1	Gearbox LH Rotation	$280.77	Add to Cart
5	5706-4	Seal Protector Plate	$4.81	Add to Cart
6	6732-6	Connecting Shaft (7?)
7	P007	Gasket Cap P788030	$2.70	Add to Cart
8	5066	Connector Tube 9 5 16	$49.21	Add to Cart
9	7798	Discharge Chute (3-1/2 x 11-1/2)
	7794	48GHS Dschrg Chte WO Spg	$110.25	Add to Cart
10	7726	Chute Hinge 2x11	$15.51	Add to Cart
11	7755	Chute Lower Lip
12	5162	Roller Wheel 5 Rubber	$13.40	Add to Cart
13	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
14	7705-1	Blade 25 RH Rotation	$37.09	Add to Cart
15	5706	Blade Hub Trash Guard	$37.05	Add to Cart
16	7705-2	Blade 25LH Rotation	$37.09	Add to Cart
	7705-3	48GHS Blade Set WHubs	$143.96	Add to Cart
17	5747-6	Safety Tread (6 x 18)
18	7701	NR 48GHS Deck Housing	$843.89	Add to Cart
19	5775-2	Hitch Pin 6	$3.24	Add to Cart
20	NS	Deck Serial Number Plate
21	7751	NR Tee Gearbox 121 Ratio	$345.66	Add to Cart
22	6732-2	Connecting Shaft (4?)
23	5052-3	1375x750x187 Washer	$3.84	Add to Cart
24	5061	Connector Tube 6 11 16	$44.21	Add to Cart
25	5747-0	Safety Tread (3 x 6)
26	7785	NR 48 Gearbox Cover9302	$72.41	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F036	1420x12 SBH Screw	$0.43	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F079	66AAD Alum Pop Rivet 316 Diax 38 Grip	$0.65	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F229	CClip 1316	$0.50	Add to Cart
