PARTS > DECKS MANUALS > 1997-07-31, 5000-5 > DML42 Deck Assembly (Non-Tilt):

Diagram #	Part #	Description	Price	Add to Cart
1	5745	PTO Shaft Guard
2	5285	Universal Joint Shaft Assembly (Includes Item # F076)
3	6054	Spline Coupling	$12.09	Add to Cart
4	5052-1	Gearbox LH Rotation	$280.77	Add to Cart
5	5706-4	Seal Protector Plate	$4.81	Add to Cart
6	6732-3	Connecting Shaft (6?)
7	P007	Gasket Cap P788030	$2.70	Add to Cart
8	5063	SU50632 Connector Tube 858	$41.84	Add to Cart
9	5162	Roller Wheel 5 Rubber	$13.40	Add to Cart
10	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
11	5705-10	Blade 21 Lower Mulching	$34.65	Add to Cart
12	5705-11	Blade 22 Upper Mulching	$35.64	Add to Cart
	5705-12	42DML Blade Set WHubs	$195.62	Add to Cart
13	5706	Blade Hub Trash Guard	$37.05	Add to Cart
14	5747-1	Safety Tread (6x19)
15	5701-1	42DML Deck Housing	$877.38	Add to Cart
16	5775-2	Hitch Pin 6	$3.24	Add to Cart
17	NS	Deck Serial Number Plate
18	5051	NR Tee Gearbox	$307.02	Add to Cart
19	5053-1	Gearbox RH Rotation	$279.09	Add to Cart
20	6732-1	Connecting Shaft (2?)
21	5062	Connector Tube 4 3 8	$37.93	Add to Cart
22	5052-3	1375x750x187 Washer	$3.84	Add to Cart
23	5747-0	Safety Tread (3x6)
24	5785	42 Gearbox Cover	$62.73	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F229	CClip 1316	$0.50	Add to Cart
