Part Lookup Tool

PARTS > DECKS MANUALS > 2014-06-18, 5000-21 European > DR52B-3 Carrier Frame Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	2744-1	Spring Clip Bracket	$8.11	Add to Cart
2	5975-3	Cable Tie 50x7	$0.36	Add to Cart
3	5743-12	Spring Cover	$11.04	Add to Cart
4	5743-13	Extension Spring	$46.42	Add to Cart
5	2723-10	Counter Weight Spring Mount DR64	$8.27	Add to Cart
6	2723-5	Locking Arm/LH	$13.67	Add to Cart
7	5830	Grease Fitting 1428	$2.47	Add to Cart
8	2667-1	Pivot MountLH	$52.38	Add to Cart
9	2723-4	Pivot Shaft	$13.53	Add to Cart
10	2667-2	Pivot MountRH	$51.39	Add to Cart
11	2723-6	Locking Arm/RH	$13.67	Add to Cart
12	2215-2	Gas Spring Cover RH	$23.96	Add to Cart
13	2723-2	Outer Height Adj Plate	$23.23	Add to Cart
14	7775-9	Wire Lock Pin516x138	$10.06	Add to Cart
15	2720-3	Spacer 916x516x438	$7.13	Add to Cart
16	2723-1	Inner Height Adj Plate	$31.59	Add to Cart
17	2215-3	Gas Spring Cover LH	$25.92	Add to Cart
18	8740	Deck Pin Bushing 34ID	$13.29	Add to Cart
19	2911-7	DR52 Carrier Frame
20	7775-5	Lock Pin 516x158	$6.82	Add to Cart
21	8811-25	NR Tilt Bar WGrip 35	$37.55	Add to Cart
22	5850-5	Handle Grip 1x1x334	$4.80	Add to Cart
23	8769-8	Dust Cap Deck Caster	$10.62	Add to Cart
24	8769-6	Bearing Cone 1ID	$11.86	Add to Cart
25	8769-5	Bearing Cup 2x158	$7.52	Add to Cart
26	8769-7	Seal	$5.66	Add to Cart
27	2770	Caster Wheel Fork	$69.72	Add to Cart
28	7038	Wheel Axle34x5916	$43.85	Add to Cart
29	8037-1	Seal- Outer (1-3/4x1-1/8)	$7.16	Add to Cart
30	8037	Bearing Cone 34ID	$12.09	Add to Cart
31	8035	Tail Whl& Tire(13x5.00-6) (W/Bearing Race)	$75.08	Add to Cart
32	8768-2	Seal Reverse Lip	$10.08	Add to Cart
33	8038-1	Spacer Wheel Axle 750xIDx1125OD	$12.61	Add to Cart
34	8039	Nut Tail Wheel Axle	$6.91	Add to Cart
35	2722-5	Deck Height AdjustmentLH DRD52	$59.83	Add to Cart
36	2214-10	Rod EndFemale 3824	$14.70	Add to Cart
37	2722-4	Pivot Shaft	$15.33	Add to Cart
38	2655	Lift Chain	$5.83	Add to Cart
39	4407-4	Bow Tie Cotter Pin	$0.68	Add to Cart
40	2215-4	Height Adjustment Rod OAL 1658	$13.01	Add to Cart
41	5146-1	10mm Ball Stud x 58	$4.63	Add to Cart
42	5146	10mm Ball Stud	$3.77	Add to Cart
43	2215	Gas Spring Assembly	$17.89	Add to Cart
44	2721-3	Lifting ArmDRD52	$287.91	Add to Cart
45	2721-2	Lifting Cross Tube
46	2723-7	Height Adj ArmDRD52	$24.53	Add to Cart
47	5850-3	Handle Grip Foam 314	$9.72	Add to Cart
48	2722-7	Foot Pedal Pad	$31.20	Add to Cart
49	2722-6	Deck Height Adj Trigger DRD52	$109.52	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F048	12 SAE Washer	$0.50	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F071	34 External Snap Ring	$0.58	Add to Cart
	F090	1420x212 Hex Bolt	$1.30	Add to Cart
	F132	1420x234 Hex Bolt	$1.42	Add to Cart
	F205	51618x14 Set Screw Knurl Point	$0.94	Add to Cart
	F215	3816x12x12 SBolt	$6.67	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F219	71614x114 Hex Bolt	$2.06	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F241	375x875x10 Washer	$0.79	Add to Cart
	F263	114 External Snap Ring	$0.94	Add to Cart
	F268	51618x3 Hex Bolt	$1.97	Add to Cart
	F298	3824 Jam Nut	$0.65	Add to Cart
	F344	3416 Slotted Hex Nut	$3.12	Add to Cart
	F347	34 SAE Washer	$1.18	Add to Cart
	F348	18x112 Cotter Pin	$0.18	Add to Cart
	F378	3816x6 Hex Bolt	$4.18	Add to Cart
	F432	316x12 Split Spring Pin	$0.34	Add to Cart
	F436	316x118 Roll Pin	$0.50	Add to Cart
	F437	Clevis Pin 14x1	$0.94	Add to Cart
	F438	51618x234 Hex Bolt	$0.50	Add to Cart
	F545	Retention Washer 250 Wire	$2.06	Add to Cart
	F548	Retention Ring 235 Wire	$0.65	Add to Cart
