Part Lookup Tool

PARTS > DECKS MANUALS > 2024-10-16, 5000-88 > DR64B-3 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	2703-5	Knob 1024x12	$5.38	Add to Cart
2	2723-18	Spindle Cover RHDR64	$19.79	Add to Cart
3	2787-10	Belt Cover (Includes Items # 4, F037,
	F086	10 SAE Washer	$0.18	Add to Cart
4	8735-8	Rubber Mat 212 x 12	$9.62	Add to Cart
5	8790	Rubber Cushion Strip	$4.51	Add to Cart
6	2723-17	Spindle Cover LHDR64	$22.79	Add to Cart
7	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
8	6715-6	Axle Spacer Tube	$2.48	Add to Cart
9	6715-3	Roller Wheel Bearing	$8.45	Add to Cart
10	6715-2	Roller Wheel 4x2x2316	$8.40	Add to Cart
11	2910-8	DR64 Deck Housing	$2,550.00	Add to Cart
12	2720-8	"Deck Height Adjustment Clevis "	$18.91	Add to Cart
13	NS	Deck Serial Number Plate
14	2619-5	PTO Shaft Guard
15	2039-2	Cover, PTO Shaft Guard (Includes Item # 16)
16	8788-1	Rubber Mat 1x2	$2.16	Add to Cart
17	2039-1	PTO Shaft Guard 64, Long
18	2039-3	Wear Disc
19	5108-11	Friction Washer 062	$1.44	Add to Cart
20	8285-4	UJnt Shaft AssySpline	$209.06	Add to Cart
21	2039-4	PTO Shaft Guard Plate
22	5270	Bearing WCollar 1	$45.28	Add to Cart
23	2726-2	PTO Bearing Housing	$70.27	Add to Cart
24	2726-5	PTO Drive Shaft 6968	$25.30	Add to Cart
25	5270-1	Ball Bearing	$9.20	Add to Cart
26	2240-11	Drive Pulley 334	$41.78	Add to Cart
27	2724-14	Idler Mount Weldment	$21.84	Add to Cart
28	5195-2	Compress Spring 1x638 Black	$8.26	Add to Cart
29	2724-17	Guide Rod Bushing	$21.20	Add to Cart
30	2725-8	Mount Base	$34.50	Add to Cart
31	2723-16	Guide Rod 858 Clear Zinc	$18.82	Add to Cart
32	2724-19	Guide Rod Stop	$7.34	Add to Cart
33	2245-6	Idler Pulley Shaft	$15.95	Add to Cart
34	7245-2	Idler Pulley	$33.88	Add to Cart
35	5245-5	Idler Pulley 214	$20.69	Add to Cart
36	2240-9	Blade Drv Pulley 38 WShield	$42.81	Add to Cart
37	5245-9	Idler Mount	$11.42	Add to Cart
38	2731-5	Blade Drive Belt 1340 L4K	$75.10	Add to Cart
39	2265	Bearing 20MM	$7.72	Add to Cart
40	2245-2	Idler Pulley	$80.05	Add to Cart
41	2052-1	Blade Spindle	$152.04	Add to Cart
42	7705-28	Blade 22166	$29.44	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F037	1024x58 PTH Screw	$0.18	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F041	3816x134 Hex Bolt	$1.87	Add to Cart
	F048	12 SAE Washer	$0.50	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F066	14x14x34 Key	$1.54	Add to Cart
	F067	316x316x1 Key	$1.99	Add to Cart
	F086	10 SAE Washer	$0.18	Add to Cart
	F123	1 External Snap Ring	$1.27	Add to Cart
	F178	14x1 Fender Washer	$1.42	Add to Cart
	F191	38x112x316 Washer	$4.26	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F262	3816x4 Hex Blt All Thrd	$2.88	Add to Cart
	F265	1220x112 Hex Bolt	$2.62	Add to Cart
	F306	3816x34 Hex Bolt	$1.06	Add to Cart
	F318	3816x34 SQH Set Screw	$0.74	Add to Cart
	F336	3816 Jam Nut	$0.34	Add to Cart
	F362	AA62D Alum Pop Rivet 316Dx1332L	$0.48	Add to Cart
	F388	3816x212 Hex Bolt	$2.26	Add to Cart
	F404	5818 Jam Nut	$1.30	Add to Cart
	F408	71620 Jam Nut	$0.96	Add to Cart
	F445	178 Internal Snap Ring	$1.66	Add to Cart
	F458	Washer 114x58x316	$4.31	Add to Cart
	F478	51618x314 Hex Bolt	$2.16	Add to Cart
	F551	51618 Flange Top Lock Nut	$1.06	Add to Cart
	F569	1420 Flange Top Lock Nut	$1.20	Add to Cart
	F571	51618x78 Carriage Bolt	$2.29	Add to Cart
	F607	1420x1 Flange Head Hex Bolt	$1.88	Add to Cart
	F608	5/16-18 x 1-3/4 Carriage Bolt
