PARTS > DECKS MANUALS > 2026-01-15, 5000-93 > DS48B-2 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8618-1	Cover PTO Shaft Guard	$21.27	Add to Cart
2	8618-10	"PTO Shaft Guard Assembly "	$53.40	Add to Cart
3	7285-5	UJoint ShaftSplined Keyed	$313.32	Add to Cart
4	6711-12	DMDS48 GearboxTube Assembly HD ProGear	$1,707.00	Add to Cart
5	6054	Spline Coupling	$12.09	Add to Cart
6	5068-6	ORing 178x2	$0.80	Add to Cart
7	5066-2	Connector Tube 9343 ORing	$56.22	Add to Cart
8	6733-6	Connecting Shaft 7	$38.57	Add to Cart
9	5052-13	HD Gearbox 11 CCWCCW	$488.88	Add to Cart
10	5051-5	HD Tee Gearbox 11 CWCWCCW	$516.39	Add to Cart
11	6733-2	Connecting Shaft 418	$41.27	Add to Cart
12	5061-2	Connector Tube 6718 ORing	$51.06	Add to Cart
13	5053-3	HD Gearbox 11 CWCCW	$498.12	Add to Cart
14	5589-1	1420x112 Stud Threadlocker	$2.15	Add to Cart
15	5747-10	Rubber Mat NoHole 3x6	$5.10	Add to Cart
16	7785-6	48 Gearbox Cover	$85.91	Add to Cart
17	8670	TiltUp Hook	$34.85	Add to Cart
18	5727-1	Washer Shim 58ID	$4.25	Add to Cart
19	5162-12	Roller Wheel 5Poly	$17.37	Add to Cart
20	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
21	NS	Deck Serial Number Plate
22	5706	Blade Hub Trash Guard	$37.05	Add to Cart
23	5705-11	Blade 22 Upper Mulching	$35.64	Add to Cart
24	7705-1	Blade 25 RH Rotation	$37.09	Add to Cart
25	7703-8	48NZ Mlch BaffleRmvable	$104.33	Add to Cart
26	7775-1	Hitch PinLH Silver 6	$4.82	Add to Cart
27	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
28	8788-1	Rubber Mat 1x2	$2.16	Add to Cart
29	7703-6	NR DS48B Deck Housing GB Cover Change	$1,577.00	Add to Cart
30	7775-2	Hitch PinRH Gold 6	$5.08	Add to Cart
31	7707-10	48SD Skid Bar04	$52.89	Add to Cart
32	6709-7	End Backup Plate48	$10.61	Add to Cart
33	6709-9	DS48 Discharge ShieldRubber	$35.84	Add to Cart
34	6709-4	48SD Rubber Shield Frame	$95.07	Add to Cart
35	5703-16	Wrench	$11.28	Add to Cart
36	5703-1	Knob 1213	$23.06	Add to Cart
37	5727	Washer Shim 12ID	$6.82	Add to Cart
38	6709-6	Center Backup Plate48	$20.90	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F118	1420 Knurled Insert Grip Range 027 to 165	$2.06	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F278	38 Split Lock Washer	$0.18	Add to Cart
	F318	3816x34 SQH Set Screw	$0.74	Add to Cart
	F390	1420x78 Carriage Bolt	$0.65	Add to Cart
	F403	1420x12 PTHMS SS	$1.18	Add to Cart
	F404	5818 Jam Nut	$1.30	Add to Cart
	F517	Washer 38x118x18	$1.58	Add to Cart
	F568	1024 Flange Top Lock Nut	$1.56	Add to Cart
	F641	1420x58 Hex Bolt SS	$0.68	Add to Cart
