PARTS > MR MANUALS > 2021-09-20, 1000-4, Serial 165963-174104 > DS54-R Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	1620-1	Belt Drive Cover	$35.00	Add to Cart
2	8790	Rubber Cushion Strip	$4.51	Add to Cart
3	1619-3	Drive Belt Guard
4	7307-1	Shock Mount 10x25 Double Stud	$5.66	Add to Cart
5	1701-15	Deck Belt Cover
6	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
7	5162-12	Roller Wheel 5Poly	$17.37	Add to Cart
8	7775-1	Hitch PinLH Silver 6	$4.82	Add to Cart
9	5727-1	Washer Shim 58ID	$4.25	Add to Cart
10	7434-1	Washer 138x5812 Thick Rubber	$2.95	Add to Cart
11	7307-9	Pull Through Bumper	$1.67	Add to Cart
12	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
13	1702	DS54-R Deck Housing (Includes Item # 12)
14	NS	Deck Serial Number Plate
15	6715-3	Roller Wheel Bearing	$8.45	Add to Cart
16	6715-4	SU6715 6 Axle Spacer Tube	$13.60	Add to Cart
17	6715-2	Roller Wheel 4x2x2316	$8.40	Add to Cart
18	1702-70	Baffle
19	1709-5	Backup Plate	$25.98	Add to Cart
20	1709-3	Rubber ShieldMRDU	$46.29	Add to Cart
21	1709-6	Discharge Shield Frame	$29.00	Add to Cart
22	7775-2	Hitch PinRH Gold 6	$5.08	Add to Cart
23	5245-2	Idler Pulley 234	$21.01	Add to Cart
24	5247-2	VGroove Idler 4	$31.77	Add to Cart
25	1731-2	Blade Drive BeltDS54R	$122.85	Add to Cart
26	6240-26	Spindle Pulley 525	$22.18	Add to Cart
27	6325-2	Spacer Bushing 516 625x376x313	$4.51	Add to Cart
28	4401-4	Washer 134x38x14Thk	$5.40	Add to Cart
29	7245-2	Idler Pulley	$33.88	Add to Cart
30	7201-3	Fiberglide Bearing	$6.91	Add to Cart
31	5830	Grease Fitting 1428	$2.47	Add to Cart
32	1702-9	Idler Arm DS54R	$42.42	Add to Cart
33	5221	Extension Spring 34x4	$7.12	Add to Cart
34	7201-4	Inner Race 112	$11.75	Add to Cart
35	8052-5	Blade Spindle	$80.35	Add to Cart
36	7705-42	Blade 18667 DS54R	$22.95	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F019	1420 ESNA Wing Nut	$4.06	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F041	3816x134 Hex Bolt	$1.87	Add to Cart
	F042	3816x214 Hex Bolt	$1.97	Add to Cart
	F048	12 SAE Washer	$0.50	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F108	3816x2 Hex Bolt	$1.42	Add to Cart
	F169	51618x1 Carriage Bolt	$0.79	Add to Cart
	F170	516x1x764 Flat Washer Zinc Plate	$1.75	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F241	375x875x10 Washer	$0.79	Add to Cart
	F265	1220x112 Hex Bolt	$2.62	Add to Cart
	F404	5818 Jam Nut	$1.30	Add to Cart
	F405	3816x112 FHA Screw SS	$3.24	Add to Cart
	F458	Washer 114x58x316	$4.31	Add to Cart
	F477	1420x58 Carriage Bolt	$1.30	Add to Cart
	F478	51618x314 Hex Bolt	$2.16	Add to Cart
	F500	316x316x916 Key	$1.54	Add to Cart
	F551	51618 Flange Top Lock Nut	$1.06	Add to Cart
	F569	1420 Flange Top Lock Nut	$1.20	Add to Cart
	F571	51618x78 Carriage Bolt	$2.29	Add to Cart
	F665	Washer 10x406x062	$2.10	Add to Cart
