PARTS > DECKS MANUALS > 1997-07-31, 5000-5 > DSD36 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5745	PTO Shaft Guard
2	5285	Universal Joint Shaft Assembly (Includes Item # F076)
3	5052-1	Gearbox LH Rotation	$280.77	Add to Cart
4	6732-2	Connecting Shaft (4?)
5	5706-4	Seal Protector Plate	$4.81	Add to Cart
6	P007	Gasket Cap P788030	$2.70	Add to Cart
7	5061	Connector Tube 6 11 16	$44.21	Add to Cart
8	6054	Spline Coupling	$12.09	Add to Cart
9	5705-1	NR Blade 20RH Rotation	$31.66	Add to Cart
	5705-5	36SD Blade Set WHubs	$133.67	Add to Cart
10	5706	Blade Hub Trash Guard	$37.05	Add to Cart
11	5747-1	Safety Tread (6 x 19)
12	5702-3	36? Deck Housing, SD (Includes Item #11)
13	5775-2	Hitch Pin 6	$3.24	Add to Cart
14	5709-2	NR 3642SD Discharge Shield	$96.35	Add to Cart
15	NS	Deck Serial Number Plate
16	5051	NR Tee Gearbox	$307.02	Add to Cart
17	5053-1	Gearbox RH Rotation	$279.09	Add to Cart
18	5060	Connector Tube 2 5 16	$48.73	Add to Cart
19	5052-3	1375x750x187 Washer	$3.84	Add to Cart
20	5747-0	Safety Tread (3 x 6)
21	5746	36 Gearbox Cover	$36.59	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F229	CClip 1316	$0.50	Add to Cart
