PARTS > DECKS MANUALS > 2008-08-01, 5000-19 > DSD36 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8618-1	Cover PTO Shaft Guard	$21.27	Add to Cart
2	8619-2	NR PTO Shaft Guard 3656SD	$16.72	Add to Cart
	8618-3	PTO Shft Grd Assy 3656SD	$54.45	Add to Cart
3	5285-15	UJnt Shaft90degSpline	$332.01	Add to Cart
4	7275-16	UJnt Tube AssySpline 10 OAL	$217.77	Add to Cart
5	5275-15	NR UJnt Tube95OALSpline	$154.77	Add to Cart
6	5704-43	36SD Gearbox Tube Assy	$714.36	Add to Cart
	5704-46	36SD Grbx Tube Assy HD	$923.76	Add to Cart
7	5704-1	Gearbox Cover Support	$9.55	Add to Cart
8	5706-4	Seal Protector Plate	$4.81	Add to Cart
9	6054	Spline Coupling	$12.09	Add to Cart
10	P007	Gasket Cap P788030	$2.70	Add to Cart
11	5061	Connector Tube 6 11 16	$44.21	Add to Cart
12	6732-2	Connecting Shaft (4-1/8)
13	5052-1	Gearbox LH Rotation	$280.77	Add to Cart
	5052-5	(NR) Gearbox- HD (LH Rotation)	$243.69	Add to Cart
14	5051-16	Tee Gearbox Shear Less Flanges	$195.32	Add to Cart
	5051-6	Tee Gearbox Shear	$262.08	Add to Cart
15	5060	Connector Tube 2 5 16	$48.73	Add to Cart
16	5053-1	Gearbox RH Rotation	$279.09	Add to Cart
	5053-5	(NR) Gearbox- HD (RH Rotation)	$246.50	Add to Cart
17	5052-3	1375x750x187 Washer	$3.84	Add to Cart
18	5747-11	Rubber Mat 3x6	$7.64	Add to Cart
19	5746-4	NR 36 Gearbox Cover02	$80.49	Add to Cart
20	5830	Grease Fitting 1428	$2.47	Add to Cart
21	8067-13	Shr Pin WCotter Set5 Softer Pin WX Mark	$11.90	Add to Cart
22	8670	TiltUp Hook	$34.85	Add to Cart
23	5162-11	"Roller Wheel (5""Poly)"	$9.05	Add to Cart
24	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
25	5710-18	36SD Deck Housing	$997.92	Add to Cart
26	NS	Deck Serial Number Plate
27	5705-1	NR Blade 20RH Rotation	$31.66	Add to Cart
	5705-5	36SD Blade Set WHubs	$133.67	Add to Cart
28	5706	Blade Hub Trash Guard	$37.05	Add to Cart
29	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
30	7775-1	Hitch PinLH Silver 6	$4.82	Add to Cart
31	8788-1	Rubber Mat 1x2	$2.16	Add to Cart
32	7775-2	Hitch PinRH Gold 6	$5.08	Add to Cart
33	5709-2	NR 3642SD Discharge Shield	$96.35	Add to Cart
34	5727-1	Washer Shim 58ID	$4.25	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F179	1420x1 Hex Bolt	$0.65	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F229	CClip 1316	$0.50	Add to Cart
	F246	1420x12 PTHMS	$0.34	Add to Cart
	F278	38 Split Lock Washer	$0.18	Add to Cart
	F295	316x112 Split Spg Pin	$0.64	Add to Cart
	F403	1420x12 PTHMS SS	$1.18	Add to Cart
