PARTS > DECKS MANUALS > 2010-09-22, 5000-20 > DSD52 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8789-5	NR Pulley GuardTilt	$49.32	Add to Cart
2	8786-15	Footrest Assembly	$201.71	Add to Cart
3	8754-3	Edge Molding	$1.30	Add to Cart
4	8754-10	52SD Cover PlateTilt	$142.28	Add to Cart
5	8245	Idler Pulley 6	$53.99	Add to Cart
6	8755	NR Blade Drv Pulley 378	$43.67	Add to Cart
7	8762	SU8762 1 Dampening Spring Gas	$35.97	Add to Cart
8	5146	10mm Ball Stud	$3.77	Add to Cart
9	8373-3	NR Idler Arm 2Hole	$20.72	Add to Cart
10	5830	Grease Fitting 1428	$2.47	Add to Cart
11	8374-1	NR Idler Arm Guide	$15.86	Add to Cart
12	7201-3	Fiberglide Bearing	$6.91	Add to Cart
13	7201-4	Inner Race 112	$11.75	Add to Cart
14	5841	Retainer Washer 38x114	$1.42	Add to Cart
15	8736	Blade Drive Belt R3VX10002	$72.28	Add to Cart
16	6240-2	NR Drive Pulley 4123V	$61.15	Add to Cart
17	8787	NR Deck Cover Knob	$6.82	Add to Cart
18	8786-10	Rubber Mat 6x1012	$15.07	Add to Cart
19	6206	Pressure Relief Valve
20	8745-25	NR Dolly WheelPTO Grd Assy	$239.82	Add to Cart
21	6715	Roller Wheel 378	$9.07	Add to Cart
22	8810-30	Tilt Dolly Mount Frame	$40.41	Add to Cart
23	8810-34	Axle Dolly Mount	$12.06	Add to Cart
24	8285-2	NR UJnt Shaft AssyTScope	$739.62	Add to Cart
25	5830-3	Grease Fitting 45 Deg	$4.04	Add to Cart
26	8788	NR Rubber Bumper SelfAdhesive Mount	$2.62	Add to Cart
27	8745-14	Retract Lever	$11.57	Add to Cart
28	5850-1	Handle Grip
29	8745-12	Actuator Link	$6.41	Add to Cart
30	8745-13	Dolly Wheel Mount	$25.08	Add to Cart
31	8745-15	Axle Spacer Tube	$6.23	Add to Cart
32	5229	Ext Spring 12x214	$7.56	Add to Cart
33	8745-20	NR Mount Bracket	$56.05	Add to Cart
34	5103-4	Pivot Bushing 38ID	$5.16	Add to Cart
35	8745-40	NR PTO Cover Plate	$38.28	Add to Cart
36	8051-11	NR Right Angle Gearbox	$495.81	Add to Cart
37	8727	Washer Shim 1316x14	$5.45	Add to Cart
38	8775	Hitch Pin 219	$4.86	Add to Cart
39	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
40	8790	Rubber Cushion Strip	$4.51	Add to Cart
41	NS	Deck Serial Number Plate
42	8810-10	NR 52SD Deck Housing	$2,304.00	Add to Cart
43	8692-10	Baffle, DSD52
44	8052-2	NR Blade Spindle	$145.01	Add to Cart
45	5705-25	Blade Spacer	$18.92	Add to Cart
46	5705-14	Blade 1812	$30.80	Add to Cart
	8738-7	NR 52SD Blade Set	$94.12	Add to Cart
47	8910-5	NR Tie Down Strap	$20.39	Add to Cart
48	8707	5262SD Skid Bar	$27.61	Add to Cart
49	8709	NR 5262SD Discharge Shield	$155.82	Add to Cart
50	5052-3	1375x750x187 Washer	$3.84	Add to Cart
51	8670-10	NR TiltUp Hook	$24.73	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F023	1024 ESNA Nut	$0.34	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F041	3816x134 Hex Bolt	$1.87	Add to Cart
	F046	3816x312 Hex Bolt	$2.88	Add to Cart
	F048	12 SAE Washer	$0.50	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F052	516 Ext Star Lock Wshr	$0.18	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F068	18x1 Cotter Pin	$0.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F108	3816x2 Hex Bolt	$1.42	Add to Cart
	F114	51618x58 SQH Set Screw	$0.65	Add to Cart
	F134	AN960816L Washer	$0.65	Add to Cart
	F168	516 Split Lock Washer	$0.18	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F246	1420x12 PTHMS	$0.34	Add to Cart
	F252	1024x34 PFHMS	$0.18	Add to Cart
	F276	5811 Jam Nut	$1.42	Add to Cart
	F277	316x58 Woodruff Key 605	$2.87	Add to Cart
	F295	316x112 Split Spg Pin	$0.64	Add to Cart
	F339	51618X34 SelfTapping Bolt	$2.28	Add to Cart
	F343	1220x2 Hex Bolt	$2.78	Add to Cart
	F354	516 Knurled Thread Insert Grip Range 027150	$2.88	Add to Cart
	F355	3816x4 Hex Bolt	$2.45	Add to Cart
	F356	1420x58 PTHMSSS	$2.45	Add to Cart
	F458	Washer 114x58x316	$4.31	Add to Cart
