PARTS > DECKS MANUALS > 1997-07-31, 5000-5 > DSD54 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5745	PTO Shaft Guard
2	5285	Universal Joint Shaft Assembly (Includes Item # F076)
3	6054	Spline Coupling	$12.09	Add to Cart
4	6732-5	NR Connecting Shaft 1118	$32.43	Add to Cart
5	5052-1	Gearbox LH Rotation	$280.77	Add to Cart
6	5706-4	Seal Protector Plate	$4.81	Add to Cart
7	P007	Gasket Cap P788030	$2.70	Add to Cart
8	5064	NR Conn Tube 13 1 2	$44.11	Add to Cart
9	6715	Roller Wheel 378	$9.07	Add to Cart
10	6716-2	Rear Axle, Anti-Scalp Roller (Bolt)
11	5705-0	Blade 20RH Rotation	$33.22	Add to Cart
	5705-9	54 56SD Blade Set W Hubs	$124.70	Add to Cart
12	5706	Blade Hub Trash Guard	$37.05	Add to Cart
13	6716-3	Front Axle, Anti-Scalp Roller (Bolt)
14	5747-1	Safety Tread (6x19)
15	6705-2	54? Deck Housing, SD (Includes Item #14)
16	5775-2	Hitch Pin 6	$3.24	Add to Cart
17	6707	NR 54SD Skid Bar	$56.74	Add to Cart
18	6709	54SD Discharge Shield	$66.05	Add to Cart
19	NS	Deck Serial Number Plate
20	5058	Tee Gearbox, Blade Drive
21	5060	Connector Tube 2 5 16	$48.73	Add to Cart
22	5051	NR Tee Gearbox	$307.02	Add to Cart
23	5053-1	Gearbox RH Rotation	$279.09	Add to Cart
24	6732-4	Connecting Shaft (5?)
25	5065	Conn Tube 7 11 16	$52.98	Add to Cart
26	5052-3	1375x750x187 Washer	$3.84	Add to Cart
27	5747-3	Safety Tread (3x11)
28	6785	NR 54SD Gearbox Cover	$44.22	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F016	1213 SelfLocking Nut	$1.51	Add to Cart
	F018	5818 Hex Nut	$1.66	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F056	58 Split Lock Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F065	316x34 Woodruff Key 606	$2.18	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F136	AN960C416L Washer	$0.29	Add to Cart
	F202	1024x58 SHC Screw GR5	$1.06	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F229	CClip 1316	$0.50	Add to Cart
