PARTS > DECKS MANUALS > 2021-06-08, 5000-57 > DU48 Complete Carrier Frame Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5975-3	Cable Tie 50x7	$0.36	Add to Cart
2	5744-1	Spring Clip Bracket	$15.81	Add to Cart
3	5743-1	Spring Cover	$13.40	Add to Cart
4	5743-3	Eye Bolt 3816x2	$8.78	Add to Cart
5	5830	Grease Fitting 1428	$2.47	Add to Cart
6	8667-3	Pivot Mount LHADJ	$70.46	Add to Cart
7	8667-4	Pivot Mount RHADJ	$82.07	Add to Cart
8	5743-6	Ext Spring 112x734 Green Spring	$21.11	Add to Cart
9	5743-8	Ext Spring 112x734 Red Spring	$24.02	Add to Cart
10	8674-11	Lever Deck LockLH	$14.86	Add to Cart
11	7406-1	Handle GripRed	$3.02	Add to Cart
12	7775-4	Detent Pin 516 x 112	$7.30	Add to Cart
13	6811-2	Tilt Bar With Grip 1412	$26.14	Add to Cart
14	5850-5	Handle Grip 1x1x334	$4.80	Add to Cart
15	5740-2	Deck Pin Bushing 58	$3.36	Add to Cart
16	8661-14	DU48 Carrier Frame
	8661-13	DU48 Carrier Frame (Includes Items #
17	8674-10	Lever Deck LockRH	$14.86	Add to Cart
18	8769-11	Bearing Cup 38 ID	$5.87	Add to Cart
19	5714-11	Bearing	$10.75	Add to Cart
20	5714-10	Axle Tube 3417	$20.94	Add to Cart
21	5715-23	Caster Wheel TireNo Flat 8x 3004 WCups Greasable	$124.74	Add to Cart
22	5770-1	Caster Wheel Fork02	$57.41	Add to Cart
23	8768-1	Seal 134x118	$6.70	Add to Cart
24	8037	Bearing Cone 34ID	$12.09	Add to Cart
25	8769-1	Bearing Cup134x1716	$7.72	Add to Cart
26	8769-10	Dust Cap Deck Caster	$10.21	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F047	3816x412 Hex Bolt	$3.12	Add to Cart
	F055	58 SAE Washer	$0.65	Add to Cart
	F068	18x1 Cotter Pin	$0.18	Add to Cart
	F098	5818 Slotted Hex Nut	$3.50	Add to Cart
	F117	Retainer Ringfor 57436	$0.58	Add to Cart
	F123	1 External Snap Ring	$1.27	Add to Cart
	F166	Retainer Ring	$0.18	Add to Cart
	F316	51618x134 Hex Bolt	$1.08	Add to Cart
	F317	316x1 Split Spring Pin	$0.50	Add to Cart
	F335	3816x78 Set ScrewSS	$2.71	Add to Cart
	F336	3816 Jam Nut	$0.34	Add to Cart
	F353	3816 ESNA LP Nut	$0.50	Add to Cart
	F489	Washer 14x78x090	$2.18	Add to Cart
	F520	1428x38 Hex Bolt	$1.54	Add to Cart
