Part Lookup Tool

PARTS > DECKS MANUALS > 2024-05-03, 5000-82 > DU48-3 Deck Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8618-1	Cover PTO Shaft Guard	$21.27	Add to Cart
2	8618-8	PTO Shaft Guard Assembly	$53.20	Add to Cart
3	7307-1	Shock Mount 10x25 Double Stud	$5.66	Add to Cart
4	8670-16	TiltUp Hook	$34.96	Add to Cart
5	8670-15	Tilt-Up Hook Spacer
6	7434-1	Washer 138x5812 Thick Rubber	$2.95	Add to Cart
7	5727-1	Washer Shim 58ID	$4.25	Add to Cart
8	5162-12	Roller Wheel 5Poly	$17.37	Add to Cart
9	8490	Roller Wheel Axle Bolt	$5.80	Add to Cart
10	5722-10	DU483 Deck Housing Advisory Bulletin 21278	$1,369.00	Add to Cart
11	7703-1	Replaceable Wear Edge48	$30.40	Add to Cart
12	NS	Deck Serial Number Plate
13	7307-9	Pull Through Bumper	$1.67	Add to Cart
14	7775-1	Hitch PinLH Silver 6	$4.82	Add to Cart
15	7775-2	Hitch PinRH Gold 6	$5.08	Add to Cart
16	8735-10	Rubber Mat 5x6	$8.35	Add to Cart
17	8788-1	Rubber Mat 1x2	$2.16	Add to Cart
18	8662-8	FootrestBelt Cover DU483	$166.11	Add to Cart
19	5747-10	Rubber Mat NoHole 3x6	$5.10	Add to Cart
20	5285-5	UJoint Shaft90 Spline Keyed	$290.01	Add to Cart
21	5270	Bearing WCollar 1	$45.28	Add to Cart
22	8726-4	Mount BasePTO Housing DU48	$150.99	Add to Cart
23	2724-17	Guide Rod Bushing	$21.20	Add to Cart
24	8645-22	8mm Nut SF007	$0.50	Add to Cart
25	2723-16	Guide Rod 858 Clear Zinc	$18.82	Add to Cart
26	2215-10	Deck Belt Dampener	$37.95	Add to Cart
27	5146	10mm Ball Stud	$3.77	Add to Cart
28	5841	Retainer Washer 38x114	$1.42	Add to Cart
29	8726-2	PTO Drive Shaft	$37.22	Add to Cart
30	5270-1	Ball Bearing	$9.20	Add to Cart
31	2245-6	Idler Pulley Shaft	$15.95	Add to Cart
32	5245-2	Idler Pulley 234	$21.01	Add to Cart
33	2240-12	Blade Pulley	$48.14	Add to Cart
34	5245-5	Idler Pulley 214	$20.69	Add to Cart
35	8731-3	Blade Drive Belt	$58.67	Add to Cart
36	5245-6	Idler Pulley Shaft	$11.62	Add to Cart
37	2265	Bearing 20MM	$7.72	Add to Cart
38	5245-4	Idler Pulley 325 MicroV	$55.86	Add to Cart
39	2245-2	Idler Pulley	$80.05	Add to Cart
40	6240-4	Drive PulleyMicroV 3	$33.92	Add to Cart
41	8724-14	Idler Mount Weldment	$19.43	Add to Cart
42	8052-5	Blade Spindle	$80.35	Add to Cart
43	7705-29	Blade 2438	$33.75	Add to Cart
44	8677	Extension Spring 1x6116	$11.99	Add to Cart
45	8678	Spring Mount Chute	$10.13	Add to Cart
46	5794	NR Dischg Chute WO Spg Mnt 612 Dia	$83.58	Add to Cart
	5794-1	Discharge Chute WSpg Mnt	$112.35	Add to Cart
47	5726	Chute Hinge 2x8	$7.75	Add to Cart
48	5755-2	Chute LipTop	$5.33	Add to Cart
49	5755-3	Chute LipBottom	$5.33	Add to Cart
50	8678-4	Spring Mount, Chute 1**
51	5794-3	Discharge Chute WSpring Mnt	$97.92	Add to Cart
52	8678-5	Spring Mount, Chute 1***
53	5794-11	Discharge Chute Assy WSpring Mount	$139.34	Add to Cart
54	5722-2	NC BaffleDU48	$19.79	Add to Cart
55	6709-11	Side Discharge AdapterDU48	$88.07	Add to Cart
56	1709-5	Backup Plate	$25.98	Add to Cart
57	1709-3	Rubber ShieldMRDU	$46.29	Add to Cart
58	1709-6	Discharge Shield Frame	$29.00	Add to Cart
59	5722-3	Kicker Baffle	$20.96	Add to Cart
60	5722-1	Housing CoverDU48	$118.13	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F014	3816 ESNA Nut	$0.65	Add to Cart
	F019	1420 ESNA Wing Nut	$4.06	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F041	3816x134 Hex Bolt	$1.87	Add to Cart
	F048	12 SAE Washer	$0.50	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F059	38 Wave Spring Washer	$1.32	Add to Cart
	F067	316x316x1 Key	$1.99	Add to Cart
	F076	3816x58 SQH Set Screw	$0.65	Add to Cart
	F087	10x78 Fender Washer	$0.65	Add to Cart
	F123	1 External Snap Ring	$1.27	Add to Cart
	F129	1024x12 PTHMS	$0.34	Add to Cart
	F169	51618x1 Carriage Bolt	$0.79	Add to Cart
	F170	516x1x764 Flat Washer Zinc Plate	$1.75	Add to Cart
	F172	1420x34 Carriage Bolt	$0.50	Add to Cart
	F191	38x112x316 Washer	$4.26	Add to Cart
	F206	2x316 Drive Pin	$0.18	Add to Cart
	F223	316x516 SemiTube Rivet	$0.44	Add to Cart
	F241	375x875x10 Washer	$0.79	Add to Cart
	F265	1220x112 Hex Bolt	$2.62	Add to Cart
	F306	3816x34 Hex Bolt	$1.06	Add to Cart
	F318	3816x34 SQH Set Screw	$0.74	Add to Cart
	F356	1420x58 PTHMSSS	$2.45	Add to Cart
	F388	3816x212 Hex Bolt	$2.26	Add to Cart
	F404	5818 Jam Nut	$1.30	Add to Cart
	F426	1420x12 Carriage Bolt	$0.50	Add to Cart
	F445	178 Internal Snap Ring	$1.66	Add to Cart
	F458	Washer 114x58x316	$4.31	Add to Cart
	F462	316x468 010 SemiTube Rivet	$0.34	Add to Cart
	F477	1420x58 Carriage Bolt	$1.30	Add to Cart
	F500	316x316x916 Key	$1.54	Add to Cart
	F504	1420 Whiz Locknut	$0.30	Add to Cart
	F551	51618 Flange Top Lock Nut	$1.06	Add to Cart
	F569	1420 Flange Top Lock Nut	$1.20	Add to Cart
	F571	51618x78 Carriage Bolt	$2.29	Add to Cart
	F601	1420x38 Torx Button Head	$2.39	Add to Cart
	F602	1420x14 TNut 14 Barrel Height	$2.87	Add to Cart
