PARTS > ADDONS MANUALS > 2009-09-01, Debris Blower > Download Complete Manual:

Diagram #	Part #	Description	Price	Add to Cart
1	NS 668745	Upper Bearing Support
2	O/L	Bolt Hex 3/8" NC x 1 1/4" GR 5
3	WLK 900036	Nut Serrated Flange 5/16" NC
4	WLK 900035	Nut Serrated Flange 3/8" NC
5	O/L	Flat Washer 7/16" Int.
6	NS 668751	Spacer Bushing
7	WLK 656229	Eye Bolt 5/16" x 5" With Nut
8	O/L	Lockwasher 3/8"
9	O/L	Bolt Hex 3/8" NC x 1 3/4" GR 5
10	NS 668744	Lower Bearing Support
11	NS 668738	Belt Guard
12	WLK 300002	Carriage Bolt 5/16" x 3/4" NC GR 5
13	O/L	Nylon Insert Locknut 5/16" NC
14	O/L	Nylon Insert Locknut 7/16" NC
15	O/L	Flat Washer 1/2" Int.
16	NS 3800072	Wheel
17	NS 100252	Bolt Hex 7/16" NC x 5 1/2" GR 5
18	WLK 1900006	Round Wire Lock Pin 1/4"
19	NS 668740	Parking Stand
20	I171 658467	11/32 Nylon Washer
21	I172 658468	7/16 Nylon Washer
22	NS 668749	Nozzle Deflector
23	NS 300003	Carriage Bolt 5/16" NC x 1" GR 5
24	I170 657309	Knob 5/16" NC
25	NS 4200031	Plastic Hand
26	NS 668742	Angling Arm
27	O/L	Spring Pin 1/8" x 3/4"
28	NS 668741	Angling Deflector
29	NS 668752	Protective Rubber
30	NS 200083	Bolt Serrated Flange 5/16" NC x 3/4" GR 5
31	NS 668739	Intake Cover
32	NS 668736	CW Impeller Housing
33	NS 200078	Bolt Serrated Flange 1/2" NC x 1" GR 5
34	O/L	Flat Washer 9/16" Int.
35	NS 668737	CW Impeller
36	NS 668735	Housing
37	NS 4300054	Bearing 1", 2 Holes 10MM, 3" C-C With Grease Fitting and Set Screws
	WLK 654106	Grease Fitting 1/4"-28 NF
38	O/L	Hex Nut 3/8" NC
39	I439 656109	Drive Shaft, 1 x 7-3/8
40	NS 664011	Pulley MA43
41	NS 668748	Spacer Bushing 0.375"
42	NS 668743	Lower Bearing Support
43	NS 668747	Spacer Bushing 1.5"
44	I461 663456	Pulley MA38
45	NS 663380	Belt AX30
46	NS 100186	Bolt Hex 3/8" NC x 2 1/2" GR 8
47	O/L	Nylon Insert Locknut 3/8" NC
48	NS 668746	Driven Shaft
49	NS 300008	Carriage Bolt 3/8" NC x 1" GR 5
	F447 655379	1/4 x 1/4 x 1 Key
