PARTS > MS MANUALS > 1997-11-05, 5000-2, Serial 20381-60135 > Electrical Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	6923	Battery Cable	$13.09	Add to Cart
2	5975-1	Cable Tie 18x334	$0.34	Add to Cart
3	5934	Battery Terminal Cap	$4.18	Add to Cart
4	5912	Battery (12V/WYB16B/Dry)
5	6392	Battery Protector Plate
6	5839	Hook Bolt	$9.35	Add to Cart
7	5844-1	Battery HoldDown Bar	$7.66	Add to Cart
8	5599	NR Pigtail Wire SetHorn67	$10.49	Add to Cart
9	5975-3	Cable Tie 50x7	$0.36	Add to Cart
10	5536-2	Horn Full Signal	$33.15	Add to Cart
11	5988-1	NR Conduit Assy Powerfil	$17.58	Add to Cart
	5988-4	NR Powerfil Tube Wire Assy	$42.11	Add to Cart
12	5984	NR Electric Contact Spring	$9.78	Add to Cart
13	5985-2	NR Power Lead Wire	$8.64	Add to Cart
14	5982-1	NR Insulator Washer 2	$3.79	Add to Cart
15	5982-2	NR Insulator Bushing	$0.50	Add to Cart
16	5975-5	Wire ClipSelfMount	$1.30	Add to Cart
17	5833	Cable Clamp 14	$1.30	Add to Cart
18	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
19	5983	NR Power Lead Wire	$4.06	Add to Cart
20	5943	Wire Harness Assembly
21	6833	Cable Clamp 916x10	$1.20	Add to Cart
22	5961	Fuse Holder Mount Bracket	$5.45	Add to Cart
23	6941-1	20 Amp Fuse	$1.87	Add to Cart
24	5940-6	NR Fuse Holder WTerminals	$6.05	Add to Cart
25	NS	Positive Battery Cable
26	NS	Voltage Regulator (Kawasaki 21066-2004)
27	5942-1	Switch Boot Fits PN 5942	$1.74	Add to Cart
28	5941-1	Switch Boot Fits PN 5941	$2.04	Add to Cart
29	5941	Safety Switch NC	$26.64	Add to Cart
30	5942	Safety Switch NO	$20.50	Add to Cart
31	5991-1	Hourmeter Power Lead Wire	$6.26	Add to Cart
32	8990	NR Hourmeter	$23.85	Add to Cart
33	5991-2	Hourmeter Ground Wire	$5.83	Add to Cart
34	5960-2	Ignition Key (1 Set)	$5.11	Add to Cart
	5960-3	Key Tip Protector	$0.34	Add to Cart
35	5960-6	NR Ignition Switch Cover	$1.08	Add to Cart
36	5960-5	Nylon Nut Ignitn Switch	$1.38	Add to Cart
37	5960	Ignition Switch (with Keys) (Includes Items# 34, 35, 36&F112)
38	5940-3	Ignition Switch Cover Svc Bulletin 9131	$3.34	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F019	1420 ESNA Wing Nut	$4.06	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F028	1024x34 PPHMS	$0.18	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F086	10 SAE Washer	$0.18	Add to Cart
	F112	58x114x03 Washer	$1.32	Add to Cart
	F147	1024x12 PPHMS SS	$0.65	Add to Cart
	F148	1024x38 PPHMS SS	$0.65	Add to Cart
	F179	1420x1 Hex Bolt	$0.65	Add to Cart
