PARTS > MT MANUALS > 2000-03-29, 8000-4, Serial 37480-54650 > Electrical Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	6923	Battery Cable	$13.09	Add to Cart
2	5975-1	Cable Tie 18x334	$0.34	Add to Cart
3	5932	Battery Trmnl InslBlk	$3.26	Add to Cart
4	5910	Battery (12V U1-SP30, Dry)
5	5933	Battery Trmnl Insul Red	$3.34	Add to Cart
6	8943	Battery Lead Wire	$5.78	Add to Cart
7	8941	Circuit Breaker 30Amp Auto ResetSealed	$11.00	Add to Cart
8	6941	Relay Switch (30/40 Amp)
9	5976-2	Grommet 316x34	$3.91	Add to Cart
10	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
11	5975-3	Cable Tie 50x7	$0.36	Add to Cart
12	7944	70 Wire Harness	$24.20	Add to Cart
	8950	NR 95100 Wire Harness	$23.47	Add to Cart
13	5536-2	Horn Full Signal	$33.15	Add to Cart
14	5961	Fuse Holder Mount Bracket	$5.45	Add to Cart
15	6941-1	20 Amp Fuse	$1.87	Add to Cart
16	5940-6	NR Fuse Holder WTerminals	$6.05	Add to Cart
17	8539	Starter Relay Mount	$4.56	Add to Cart
18	8977	Grommet 18x78	$1.74	Add to Cart
19	5941	Safety Switch NC	$26.64	Add to Cart
20	5941-1	Switch Boot Fits PN 5941	$2.04	Add to Cart
21	5975-5	Wire ClipSelfMount	$1.30	Add to Cart
22	5942	Safety Switch NO	$20.50	Add to Cart
23	5942-1	Switch Boot Fits PN 5942	$1.74	Add to Cart
24	5975-2	Cable Tie (30# x 6")
25	7942	NR Safety Switch	$59.14	Add to Cart
26	7942-0	Nut Safety Switch	$2.10	Add to Cart
27	7942-15	6WAY CONNECTOR FEMALE	$6.10	Add to Cart
28	8940-2	NR Wire Harness	$178.19	Add to Cart
29	6390	Battery Pan	$16.30	Add to Cart
30	6392	Battery Protector Plate
31	5839	Hook Bolt	$9.35	Add to Cart
32	5844	Battery HoldDown Bar	$11.42	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F019	1420 ESNA Wing Nut	$4.06	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F027	1024x58 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F078	A/A64D Aluminum Pop Rivet
	F093	51618x1 Hex Bolt	$0.94	Add to Cart
	F124	1032x38 Taptite MS	$0.36	Add to Cart
	F284	M6x10x8 SCH Screw	$0.79	Add to Cart
