PARTS > MC MANUALS > 2004-11-01, 6000-10, Serial 66220-85834 > Electrical Assembly Body:

Diagram #	Part #	Description	Price	Add to Cart
1	8960-2	Ignition Key (1 Set)
2	8960-15	Ignition Switch WKeys	$34.63	Add to Cart
3	5940-3	Ignition Switch Cover Svc Bulletin 9131	$3.34	Add to Cart
4	5975-3	Cable Tie 50x7	$0.36	Add to Cart
5	5983	NR Power Lead Wire	$4.06	Add to Cart
6	5975-5	Wire ClipSelfMount	$1.30	Add to Cart
7	5941-5	Safety Switch NO	$72.28	Add to Cart
8	7203-6	Riser Plate Seat Switch	$4.87	Add to Cart
9	5977-6	Grommet 1x114	$1.26	Add to Cart
10	6940-10	Jumper Wire	$5.78	Add to Cart
11	8996-4	Red Indicator Lens	$10.88	Add to Cart
12	8996-3	NR Indicator Bulb 89962	$7.26	Add to Cart
13	8996-2	Red Indicator Light Assembly (Includes Items# 11 & 12)
14	5991-1	Hourmeter Power Lead Wire	$6.26	Add to Cart
15	8990-1	Hourmeter Global	$25.89	Add to Cart
16	5991-2	Hourmeter Ground Wire	$5.83	Add to Cart
17	6941	Relay Switch (30/40 Amp)
18	7941-5	Circuit Breaker 7AMP	$9.88	Add to Cart
19	7941-3	Boot Circuit Breaker	$8.90	Add to Cart
20	7854	Plastic TipRed	$0.50	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F349	Washer 835ID 1122ODSS	$1.66	Add to Cart
