Part Lookup Tool

PARTS > MS MANUALS > 1997-11-05, 5000-2, Serial 20381-60135 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	5090-2	Vacuator Valve	$12.75	Add to Cart
2	5090-1	Air Cleaner Cartridge	$35.90	Add to Cart
3	NS	Air Filter Element (Donaldson P822686)
4	5088-1	Air Cleaner Band	$27.20	Add to Cart
5	7840	Hose Clamp 1516 214	$4.13	Add to Cart
6	5087	Air Intake Hose	$22.29	Add to Cart
7	5123	ThrottleChoke Mount	$7.18	Add to Cart
	5128	NR Choke Arm Mount Assy	$20.19	Add to Cart
8	NS	Oil Filter (Kawasaki 49065-2071)
9	NS	O-Ring (Kawasaki 670B2015)
10	NS	Engine Plug (Kawasaki 92066-2003)
11	NS	11 hp Engine (Kawasaki 49120-2250) (Includes Items# 10,11 & 13)
12	NS	Muffler (Kawasaki 49069-2285-9X)
13	NS	Fuel Tank (Kawasaki 51001-2258-9H)
14	5124	Choke Actuator Arm	$4.63	Add to Cart
15	5982-2	NR Insulator Bushing	$0.50	Add to Cart
16	5091	Air Flow Indicator
17	5092	Close Nipple, 3/4 (1/8 NPT)
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F023	1024 ESNA Nut	$0.34	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F190	#10 Internal Star Lock Washer
	F217	71614 Hex Nut	$0.65	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F281	71614x134 Hex Bolt	$2.54	Add to Cart
	F313	M5x8x12 Machine Screw	$0.50	Add to Cart
