PARTS > MC MANUALS > 1997-11-05, 6000-5, Serial 31040-49732 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	6016-2	NR Glass Collection Jar wo Lid	$8.81	Add to Cart
2	6016-1	NR Rubber Gasket	$7.57	Add to Cart
3	6011-0	NR Precleaner Housing	$72.81	Add to Cart
	6011-11	NR Precleaner Assembly	$87.40	Add to Cart
4	6011-10	Hose Clamp 34 to 114	$3.12	Add to Cart
5	6028	Precleaner Tube (Uses Existing Fasteners at Engine)
6	7840	Hose Clamp 1516 214	$4.13	Add to Cart
7	6029	Hose Clamp 11316 234	$3.26	Add to Cart
8	7027	NR Elbow Precleaner	$15.05	Add to Cart
9	6087	NR Air Intake HoseC16HP	$36.08	Add to Cart
10	6090	Air Cleaner (Includes Item #6)
11	5088-1	Air Cleaner Band	$27.20	Add to Cart
12	5090-1	Air Cleaner Cartridge	$35.90	Add to Cart
13	5090-2	Vacuator Valve	$12.75	Add to Cart
14	5091	Air Flow Indicator
15	5092	Close Nipple, 3/4 (1/8 NPT)
16	5082	Fuel Tank Cap (Includes Item # 17)
17	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
18	6046	Fuel Tank, 3.0 gal., Gas (Includes Items# 16,17, 24&25)
19	8023	Fuel Tank Support	$23.72	Add to Cart
20	7015	NR Hose 14x15	$11.44	Add to Cart
21	5879-3	Hose Clamp 12	$0.65	Add to Cart
22	5020	Fuel FilterNon EFI	$5.94	Add to Cart
23	6015-3	Hose 14x1212	$6.77	Add to Cart
24	5083	Fuel ShutOff Valve	$16.12	Add to Cart
25	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
26	NS	16 HP Engine (KohlerTH16S, Spec.# 2543502)
27	NS	Oil Filter (Kohler 2805001)
28	NS	Gasket (Kohler 2404102)
29	NS	Nut(KohlerM-0841080)
30	8897	NR Muffler Band Clamp	$17.18	Add to Cart
31	6052	NR Exhaust PipeRear 518	$19.93	Add to Cart
32	6051	Exhaust PipeFrnt 414	$19.67	Add to Cart
33	8013-1	Muffler Beg 95 21329	$234.38	Add to Cart
34	8013-5	NR Muffler Heat Shield	$71.42	Add to Cart
35	6327	Solenoid Mount	$5.57	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F249	M10 Split Lock Washer	$0.36	Add to Cart
	F332	M10x15x30 Hex Bolt	$1.97	Add to Cart
