PARTS > MT MANUALS > 2000-03-29, 8000-4, Serial 37480-54650 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	7026-2	Remote Precleaner	$59.33	Add to Cart
2	7440	Shock Mount 1x34	$5.20	Add to Cart
3	7028-20	Rear Precleaner Mount	$8.16	Add to Cart
4	7027	NR Elbow Precleaner	$15.05	Add to Cart
5	7840	Hose Clamp 1516 214	$4.13	Add to Cart
6	5088-10	Air CleanerDD	$118.13	Add to Cart
7	5090-3	Safety Filter Insert	$25.65	Add to Cart
8	5090-10	Air Cleaner Cartridge
9	5088-1	Air Cleaner Band	$27.20	Add to Cart
10	5090-2	Vacuator Valve	$12.75	Add to Cart
11	5091-10	Air Flow Indicator & Nipple
12	8026	Air Hose CleanerT 175IDx316Wall	$25.23	Add to Cart
13	7031	NR Tube Support Arm	$13.13	Add to Cart
14	7028-30	Precleaner Tube, SD
15	7028-2	Precleaner Tube, GHS
16	NS	Seal, 7/16 (Kohler 4103202)
17	NS	20-hp Engine
	NS	25-hp Engine (Optional or Exchange)
	NS	26-hp EFI Engine (Optional or Exchange)
18	NS	Wing Nut (Kohler 1210001)
19	NS	Cover (Kohler 2409610) (Includes Item #20)
20	NS	Air Cleaner Cover Seal (Kohler 2474318)
21	NS	Seal, 3/4 (Kohler 230046)
22	NS	Bracket (Kohler 2412622)
23	NS	Base (Kohler 2409405)
24	NS	Gasket (Kohler 2404106)
25	8015-1	Hose 14x312	$3.98	Add to Cart
26	5879-3	Hose Clamp 12	$0.65	Add to Cart
27	NS	Oil Filter (Kohler 1205001)
28	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
29	8010-6	Valve Cover Sleeve	$4.56	Add to Cart
30	8010-2	Engine Bumper Mount	$15.96	Add to Cart
31	5845	Rubber Bumper 150x125	$7.12	Add to Cart
32	5020	Fuel FilterNon EFI	$5.94	Add to Cart
33	8015	Hose 14x1412	$7.32	Add to Cart
34	5083	Fuel ShutOff Valve	$16.12	Add to Cart
35	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
36	8023	Fuel Tank Support	$23.72	Add to Cart
37	8046	Fuel Tank, 4.3 Gallon, Gas (Includes Items # 26, 34, 35, 38 & 39)
38	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
39	5082	Fuel Tank Cap (Includes Item # 38)
40	8021	Engine Brace	$9.89	Add to Cart
41	NS	Gasket (Kohler 240410 )
42	NS	Nut (Kohler M-0841080)
43	8530	Grass Shld MfflrT9503	$37.25	Add to Cart
44	8897	NR Muffler Band Clamp	$17.18	Add to Cart
45	8013-5	NR Muffler Heat Shield	$71.42	Add to Cart
46	8013-1	Muffler Beg 95 21329	$234.38	Add to Cart
47	8013-4	NR Exhaust Pipe Rear	$53.20	Add to Cart
48	8013-6	NR Exhaust Pipe Front	$48.99	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F052	516 Ext Star Lock Wshr	$0.18	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F063	38 Int Star Lock Washer	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F106	3816x58 Hex Bolt	$0.94	Add to Cart
	F175	12 Split Lock Washer	$0.50	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F255	51618x112 Hex Bolt	$1.06	Add to Cart
	F273	M6x10 Nut	$0.22	Add to Cart
	F274	M6 x 1.0 45 Stud
	F285	1213x112 Hex Bolt	$2.45	Add to Cart
	F324	M8x125x12 Hex Bolt	$1.18	Add to Cart
