Part Lookup Tool

PARTS > MW MANUALS > 2003-11-01, 9000, Serial 62821-CURRENT > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	5020	Fuel FilterNon EFI	$5.94	Add to Cart
2	5879-3	Hose Clamp 12	$0.65	Add to Cart
3	5086-18	NR Hose 14x18	$8.90	Add to Cart
4	5082	Fuel Tank Cap (Includes Item # 5)
5	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
6	5083-2	Tank Tube Elbow	$11.19	Add to Cart
7	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
8	9121-10	Throttle Control Cable	$145.01	Add to Cart
9	5108-5	NR Throttle Cntrl KnobRed	$6.05	Add to Cart
10	5020-1	Fuel Filter, In Tank
11	5086	NR Hose 14x18	$14.40	Add to Cart
12	6046-2	Fuel Tank 3.0 Gal./Gas (Includes Items# 4&5)
13	9011	Oil Pressure Switch	$17.01	Add to Cart
14	NS	Oil Filter (Kawasaki 49065-2078)
15	9237	Engine Pulley 43V3A	$77.24	Add to Cart
16	NS	15 HP Kawasaki Engine (FH430VAS14)
17	NS	Washer (Kawasaki 92002-1982)
18	NS	Bolt (Kawasaki 92151-7010)
	F002	1024 Keps Nut	$0.18	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F163	51618x34 SQH Set Screw	$0.65	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F240	14x14x214 Key	$2.10	Add to Cart
