Part Lookup Tool

PARTS > MS MANUALS > 2004-03-02, 5000-12, Serial 60136-78321 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	5090	NR Air Cleaner wValve	$150.26	Add to Cart
2	5090-2	Vacuator Valve	$12.75	Add to Cart
3	5088-5	Air Cleaner Draw Latch	$12.20	Add to Cart
4	5090-1	Air Cleaner Cartridge	$35.90	Add to Cart
5	5090-3	Safety Filter Insert	$25.65	Add to Cart
6	5088-1	Air Cleaner Band	$27.20	Add to Cart
7	7840	Hose Clamp 1516 214	$4.13	Add to Cart
8	5087	Air Intake Hose	$22.29	Add to Cart
9	5123	ThrottleChoke Mount	$7.18	Add to Cart
	5128	NR Choke Arm Mount Assy	$20.19	Add to Cart
10	NS	Oil Filter (Kawasaki 49065-2071)
11	NS	O-Ring (Kawasaki 670B2015)
12	NS	Engine Plug (Kawasaki 92066-2003)
13	NS	13 hp Engine (Kawasaki FE4000, AS04) (Includes Items# 12,13&15)
14	NS	Muffler (Kawasaki 49069-2285-9X)
15	NS	Fuel Tank (Kawasaki 51001-2258-9H)
16	5124	Choke Actuator Arm	$4.63	Add to Cart
17	5982-2	NR Insulator Bushing	$0.50	Add to Cart
18	5091-11	Air Flow Indicator & Nipple
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F023	1024 ESNA Nut	$0.34	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F190	#10 Internal Star Lock Washer
	F217	71614 Hex Nut	$0.65	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F281	71614x134 Hex Bolt	$2.54	Add to Cart
	F313	M5x8x12 Machine Screw	$0.50	Add to Cart
