Part Lookup Tool

PARTS > MB MANUALS > 2004-06-01, 4000-1, Serial 68441-79431 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	4845	Rubber Bumper 10x625	$8.50	Add to Cart
2	4104-1	NR Body Support	$22.37	Add to Cart
3	4013-1	NR Muffler Guard	$82.99	Add to Cart
4	4104-9	Heat ShieldAluminum	$52.92	Add to Cart
5	NS	18 HP Engine (Briggs & Stratton 350447)
6	7840	Hose Clamp 1516 214	$4.13	Add to Cart
7	4087	Air Intake Hose (1-1/2 ID x 2-1/4)
8	4010-5	38 NPT Street L	$10.06	Add to Cart
9	5020	Fuel FilterNon EFI	$5.94	Add to Cart
10	5879-3	Hose Clamp 12	$0.65	Add to Cart
11	5086-5	NR Hose 14x32	$13.49	Add to Cart
12	5086	NR Hose 14x18	$14.40	Add to Cart
13	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
14	5083-2	Tank Tube Elbow	$11.19	Add to Cart
15	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
16	5082	Fuel Tank Cap (Includes Item # 15)
17	4046	Fuel Tank, 3.0 Gal. Gas (Fuel Cap Centered) (Includes# 15&16)
18	5020-1	Fuel Filter, In Tank
19	5975-3	Cable Tie 50x7	$0.36	Add to Cart
20	4108-1	NR ThrttlChoke Cbl 5612	$16.26	Add to Cart
21	5172	Bearing Delrin 250x375x250 Length	$4.96	Add to Cart
22	5108-7	Control Lock Tab	$2.52	Add to Cart
23	5108-10	Friction Washer 125	$1.98	Add to Cart
24	5108-8	Control Bracket	$9.26	Add to Cart
25	5108-1	Control LeverThrottleChoke	$4.44	Add to Cart
26	5108-5	NR Throttle Cntrl KnobRed	$6.05	Add to Cart
27	5108-6	NR Choke Cntrl KnobBlack	$5.74	Add to Cart
28	7108	Control Assembly	$30.21	Add to Cart
	8121	Throttle CntrlCable Assy	$64.97	Add to Cart
	8122	Choke Cntrl Cable Assy	$65.63	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F037	1024x58 PTH Screw	$0.18	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F164	1024x14x38 SHL Bolt	$2.95	Add to Cart
	F179	1420x1 Hex Bolt	$0.65	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F201	SU F642 1 4 Belleville Spg Washer	$1.75	Add to Cart
	F255	51618x112 Hex Bolt	$1.06	Add to Cart
	F316	51618x134 Hex Bolt	$1.08	Add to Cart
	F392	1420x1 Set ScrewSS Cup Point	$1.56	Add to Cart
