Part Lookup Tool

PARTS > MS MANUALS > 2005-04-01, 5000-14, Serial 78322-117172 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	5090	NR Air Cleaner wValve	$150.26	Add to Cart
2	5090-2	Vacuator Valve	$12.75	Add to Cart
3	5088-5	Air Cleaner Draw Latch	$12.20	Add to Cart
4	5090-1	Air Cleaner Cartridge	$35.90	Add to Cart
5	5090-3	Safety Filter Insert	$25.65	Add to Cart
6	5088-1	Air Cleaner Band	$27.20	Add to Cart
7	7840	Hose Clamp 1516 214	$4.13	Add to Cart
8	5087	Air Intake Hose	$22.29	Add to Cart
9	5123	ThrottleChoke Mount	$7.18	Add to Cart
	5128	NR Choke Arm Mount Assy	$20.19	Add to Cart
10	NS	Oil Filter (Kawasaki 49065-2071)
11	NS	O-Ring (Kawasaki 670B2015)
12	NS	Engine Plug (Kawasaki 92066-2003)
13	NS	13 hp Engine (Kawasaki FE4000, AS04) (Includes Items# 12,13&14)
14	NS	Fuel Tank (Kawasaki 51001-2258-9H)
15	5124	Choke Actuator Arm	$4.63	Add to Cart
16	5982-2	NR Insulator Bushing	$0.50	Add to Cart
17	5091-11	Air Flow Indicator & Nipple
18	8123	Insulating Sleeve 38x6	$3.26	Add to Cart
19	7833	Cable Clamp 78x14	$2.72	Add to Cart
20	NS	Gasket, Muffler (Kawasaki 11061-2078)
21	NS	Washer (Kawasaki 461F0800)
22	NS	Nut (Kawasaki 317R0800)
23	5013-4	(NR) Exhaust Pipe S/04	$42.17	Add to Cart
24	5013-2	Muffler S 04	$206.59	Add to Cart
25	5013-3	NR Muffler Heat Shield S04	$39.73	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F023	1024 ESNA Nut	$0.34	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F190	#10 Internal Star Lock Washer
	F217	71614 Hex Nut	$0.65	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F281	71614x134 Hex Bolt	$2.54	Add to Cart
	F313	M5x8x12 Machine Screw	$0.50	Add to Cart
