Part Lookup Tool

PARTS > MC MANUALS > 2006-09-01, 6000-12, Serial 85835-100981 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	7026-2	Remote Precleaner	$59.33	Add to Cart
2	7840	Hose Clamp 1516 214	$4.13	Add to Cart
3	6028-1	NR Precleaner Tube	$64.89	Add to Cart
4	7027	NR Elbow Precleaner	$15.05	Add to Cart
5	6029	Hose Clamp 11316 234	$3.26	Add to Cart
6	6087-1	NR Air Intake HoseMC	$23.06	Add to Cart
7	5088-11	Air Cleaner Cap	$42.02	Add to Cart
8	5088-2	Air Cleaner Band C18	$28.01	Add to Cart
9	5090-1	Air Cleaner Cartridge	$35.90	Add to Cart
10	6090-10	NR Air Cleaner Assembly	$103.03	Add to Cart
11	5090-3	Safety Filter Insert	$25.65	Add to Cart
12	5090-2	Vacuator Valve	$12.75	Add to Cart
13	5088-5	Air Cleaner Draw Latch	$12.20	Add to Cart
14	5091-9	Street Elbow 9018x18	$6.72	Add to Cart
15	5091-11	Air Flow Indicator & Nipple
16	NS	20 HP Engine (Kohler CH20S, Spec. # 64757)
17	NS	Oil Filter (Kohler 2805001)
18	NS	Gasket (Kohler 2404102)
19	NS	Nut (Kohler M-0841080)
20	6013-3	Muffler/20HP	$225.88	Add to Cart
21	6013-7	Muffler Heat Shield 20HP	$40.48	Add to Cart
22	6013-6	NR Muffler Heat Dflctor20HP	$25.74	Add to Cart
23	6013-5	Muffler Brace20HP	$18.24	Add to Cart
24	5082	Fuel Tank Cap (Includes Item # 25)
25	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
26	5083-2	Tank Tube Elbow	$11.19	Add to Cart
27	5879-3	Hose Clamp 12	$0.65	Add to Cart
28	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
29	5086	NR Hose 14x18	$14.40	Add to Cart
30	5975-3	Cable Tie 50x7	$0.36	Add to Cart
31	8015-3	NR Hose 14x2412	$15.77	Add to Cart
32	NS	Fuel Line, Engine (Kohler)
33	5020	Fuel FilterNon EFI	$5.94	Add to Cart
34	8023	Fuel Tank Support	$23.72	Add to Cart
35	5020-2	Fuel Filter In Tank	$11.54	Add to Cart
36	6046-2	Fuel Tank, 3.0 gal., Gas (Includes Items # 24, 25 & 28)
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F063	38 Int Star Lock Washer	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F120	AN960416 Washer	$0.29	Add to Cart
	F151	3816x78 Hex Bolt	$1.18	Add to Cart
	F183	312x700x074 Washer	$0.58	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F219	71614x114 Hex Bolt	$2.06	Add to Cart
