PARTS > MS MANUALS > 2014-05-05, 5000-27, Serial 128442-144526 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	5303-4	Engine Brace
2	NS	14 HP Engine (Subaru)
3	6090-11	Air Cleaner Assembly	$117.92	Add to Cart
4	5090-1	Air Cleaner Cartridge	$35.90	Add to Cart
5	5090-3	Safety Filter Insert	$25.65	Add to Cart
6	5088-1	Air Cleaner Band	$27.20	Add to Cart
7	7840	Hose Clamp 1516 214	$4.13	Add to Cart
8	5011-8	Air Intake HoseMS	$23.01	Add to Cart
9	5879-3	Hose Clamp 12	$0.65	Add to Cart
10	5011-9	90 Degree Elbow 516	$7.66	Add to Cart
11	M247	Fuel Line Nitrile516	$13.01	Add to Cart
12	5011-11	Intake Tube	$29.68	Add to Cart
13	M247	Fuel Line Nitrile516	$13.01	Add to Cart
14	5011-12	Intake Pipe / Gasket
15	5303-7	Engine Spacer
16	NS	Nut
17	NS	Gasket, Muffler
18	5011-15	NR Muffler MSSubaru	$162.02	Add to Cart
19	5013-3	NR Muffler Heat Shield S04	$39.73	Add to Cart
20	8108-4	Control Cable 58	$14.49	Add to Cart
21	5122-3	NR Control Cable 58	$15.11	Add to Cart
22	5108-1	Control LeverThrottleChoke	$4.44	Add to Cart
23	5108-5	NR Throttle Cntrl KnobRed	$6.05	Add to Cart
24	5108-6	NR Choke Cntrl KnobBlack	$5.74	Add to Cart
25	7108	Control Assembly	$30.21	Add to Cart
	2108-2	NR Throttle CntrlCable Assy	$53.33	Add to Cart
	5121-3	NR Choke CntrlCable Assy	$69.76	Add to Cart
26	5108-8	Control Bracket	$9.26	Add to Cart
27	5108-10	Friction Washer 125	$1.98	Add to Cart
28	5108-7	Control Lock Tab	$2.52	Add to Cart
29	5172	Bearing Delrin 250x375x250 Length	$4.96	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F044	51624x34 Hex Bolt	$0.79	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F052	516 Ext Star Lock Wshr	$0.18	Add to Cart
	F164	1024x14x38 SHL Bolt	$2.95	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F201	SU F642 1 4 Belleville Spg Washer	$1.75	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F539	Washer 281x750x185	$3.72	Add to Cart
