PARTS > MC MANUALS > 2015-05-20, 6000-18, Serial 134498-147790 > Engine Group:

Diagram #	Part #	Description	Price	Add to Cart
1	4090	Air Cleaner 90 Degree 2	$157.61	Add to Cart
2	6029	Hose Clamp 11316 234	$3.26	Add to Cart
3	6087-5	Air Intake Hose
4	NS	Air Cleaner Band
5	5090-5	Safety Filter InsertVLR	$22.57	Add to Cart
6	5090-4	Air Cleaner Cartridge/VLR	$23.83	Add to Cart
7	5091-6	Air Flow Indicator W Brkt Vacuum 10 H2O	$25.61	Add to Cart
8	7334-3	Air Cleaner BracketMC	$9.84	Add to Cart
9	M258	Vacuum Hose	$3.26	Add to Cart
10	5091-0	18 Pipe Thread Male WBarb	$7.26	Add to Cart
11	5091-16	Street Elbow 9018x18	$5.54	Add to Cart
12	5845	Rubber Bumper 150x125	$7.12	Add to Cart
13	8010-2	Engine Bumper Mount	$15.96	Add to Cart
14	NS	Oil Filter (Kohler
15	NS	19 HP Kohler Engine
16	NS	Clamp (Kohler 25
17	NS	Oil Cooler Hose
18	NS	Oil Cooler (Kohler
19	8016-8	Oil CoolerReg Mount	$33.22	Add to Cart
20	NS	Gasket (Kohler
21	NS	Nut (Kohler M-0841080)
22	6013-14	Muffler19HP WSensor Clam Shell	$100.63	Add to Cart
23	6013-18	Muffler Heat Shield19HP	$43.74	Add to Cart
24	6013-19	Muffler Brace
25	8021	Engine Brace	$9.89	Add to Cart
26	NS	Sensor, Oxygen
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F063	38 Int Star Lock Washer	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F106	3816x58 Hex Bolt	$0.94	Add to Cart
	F151	3816x78 Hex Bolt	$1.18	Add to Cart
	F184	1420x12 Hex Bolt SS	$1.30	Add to Cart
	F185	14 Int Star Lck WshrSS	$0.18	Add to Cart
	F273	M6x10 Nut	$0.22	Add to Cart
	F285	1213x112 Hex Bolt	$2.45	Add to Cart
	F482	832 Nylock Nut	$0.17	Add to Cart
	F483	832x34 PPHMS	$0.17	Add to Cart
	F547	M6x10x45 Stud	$2.71	Add to Cart
	M258	Vacuum Hose	$3.26	Add to Cart
