PARTS > MT MANUALS > 2007-04-01, 8000-13, Serial 85932-100102 > Engine Group - MTL:

Diagram #	Part #	Description	Price	Add to Cart
1	5083-5	Tank Tube Elbow
2	5879-3	Hose Clamp (1/2)	$0.65	Add to Cart
3	8015-3	(NR) Hose (1/4x24-1/2)	$9.84	Add to Cart
4	NS	Fuel Pump (Kohler)
5	NS	Fuel Line (Kohler)
6	5020	Fuel Filter/Non EFI	$5.94	Add to Cart
7	5832	Cable Clamp (1/2) .203 Hole	$1.87	Add to Cart
8	5083-1	Bushing Rubber (Fits 5083)	$2.47	Add to Cart
9	5086-7	(NR) Hose (1/4x6)	$12.40	Add to Cart
10	5020-2	Fuel Filter In Tank	$11.54	Add to Cart
11	8046-9	Fuel Tank, 5 Gallon, Gas (Includes Items # 12 & 13)
12	5082-2	(NR) Fuel Cap Seal	$2.16	Add to Cart
13	5082	Fuel Tank Cap (Includes Item # 12)
14	5665	(NR) Compression Sprg (1/2x1)	$9.16	Add to Cart
15	8530-15	(NR) Muffler End Shield	$29.60	Add to Cart
16	8530-17	Upper Grass Shield	$25.83	Add to Cart
17	8013-34	(NR) Muffler Mount Tab	$7.66	Add to Cart
18	8013-31	Muffler MTL SN 75766 to 97112	$171.91	Add to Cart
19	8013-32	Exhaust Pipe MTL25	$112.63	Add to Cart
20	8013-16	(NR) Mounting Spg Muffler/MTL	$13.01	Add to Cart
21	NS	Nut (Kohler)
22	NS	Gasket (Kohler)
23	NS	Regulator (Kohler)
24	NS	Oil Filter (Kohler 1205001)
25	7958-2	Resistor Mount Plate	$20.11	Add to Cart
26	5841	Retainer Washer (3/8x1-1/4)	$1.42	Add to Cart
27	NS	25-hp Engine
28	7306-12	(NR) Temp Sender Adapter	$6.31	Add to Cart
29	7306-15	Water Temperature Sender	$42.85	Add to Cart
	F002	10-24 Keps Nut	$0.18	Add to Cart
	F004	1/4-20 Keps Nut	$0.34	Add to Cart
	F009	5/16-18 Whiz Locknut	$0.50	Add to Cart
	F012	3/8-16 Keps Nut	$0.79	Add to Cart
	F025	10-24x3/8 PPHMS	$0.18	Add to Cart
	F029	1/4-20x1/2 Hex Bolt	$0.50	Add to Cart
	F031	1/4-20x5/8 Hex Bolt	$0.50	Add to Cart
	F032	1/4-20x3/4 Hex Bolt	$0.50	Add to Cart
	F038	3/8-16x1 Hex Bolt	$1.06	Add to Cart
	F041	3/8-16x1-3/4 Hex Bolt	$1.87	Add to Cart
	F050	1/4 SAE Washer	$0.18	Add to Cart
	F051	3/8 SAE Washer	$0.65	Add to Cart
	F061	1/4 Star Lock Wshr	$0.18	Add to Cart
	F063	3/8 Int. Star Lock Washer	$0.18	Add to Cart
	F079	66AAD Alum. Pop Rivet (3/16 Dia.x 3/8 Grip)	$0.65	Add to Cart
	F091	5/16-18x5/8 Hex Bolt	$0.65	Add to Cart
	F151	3/8-16x7/8 Hex Bolt	$1.18	Add to Cart
	F187	1/4-20x1-1/2 Hex Bolt	$0.79	Add to Cart
	F188	1/4-20 Self-Locking Nut	$0.30	Add to Cart
