PARTS > MT MANUALS > 2005-09-15, 8000-12, Serial 75988-85931 > Engine Group - MTLEFI:

Diagram #	Part #	Description	Price	Add to Cart
1	8026-7	NR Hose 14x16	$7.75	Add to Cart
2	8026-5	HP Fuel Line 516x21 Regulator To Filter	$13.31	Add to Cart
3	5879-5	Stepless Ear Clamp 58	$3.38	Add to Cart
4	8026-14	NR Clamp Loop Style	$5.66	Add to Cart
5	NS	Fuel Filter (Kohler)
6	8026-12	HP Fuel Line 516x26 Filter to Engine	$25.78	Add to Cart
7	7014-7	Fuel Line Guard	$11.84	Add to Cart
8	8026-11	NR HP Fuel Line 516x16 Pump To Regulator	$17.31	Add to Cart
9	8026-8	Vent Tube Regulator	$3.19	Add to Cart
10	NS	Fuel Regulator (Kohler)
11	5879-3	Hose Clamp 12	$0.65	Add to Cart
12	7014-2	Regulator/Filter Mount
13	7833	Cable Clamp 78x14	$2.72	Add to Cart
14	NS	Fuel Pump (Kohler)
15	NS	Clamp (Kohler)
16	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
17	7014-5	Fuel Pump Mount	$19.01	Add to Cart
18	7014-6	NR Fuel Pump Cover	$10.22	Add to Cart
19	8026-9	NR Hose 516x8 Tank to Pump	$6.60	Add to Cart
20	5083-2	Tank Tube Elbow	$11.19	Add to Cart
21	5083-4	Plug Bushing Viton	$7.56	Add to Cart
22	5086-7	NR Hose 14x6	$12.40	Add to Cart
23	5020-2	Fuel Filter In Tank	$11.54	Add to Cart
24	8046-4	Fuel Tank, 5.0 Gallon, Gas, MTLEFI (Includes Items# 25, 26&27)
25	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
26	5082	Fuel Tank Cap (Includes Item # 25)
27	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
28	7046-1	Fuel Return Tube	$8.30	Add to Cart
29	5665	NR Compression Sprg 12x1	$9.16	Add to Cart
30	8530-15	NR Muffler End Shield	$29.61	Add to Cart
31	8530-17	Upper Grass Shield	$25.83	Add to Cart
32	8013-34	NR Muffler Mount Tab	$11.68	Add to Cart
33	8013-31	Muffler MTL SN 75766 to 97112	$171.91	Add to Cart
34	8013-16	NR Mounting Spg MufflerMTL	$13.01	Add to Cart
35	8013-33	NR Exhaust Pipe MTL31	$109.83	Add to Cart
36	NS	Nut (Kohler)
37	NS	Gasket (Kohler)
38	NS	Oxygen Sensor (Kohler)
39	NS	Oil Filter (Kohler 1205001)
40	7958-2	Resistor Mount Plate	$20.11	Add to Cart
41	NS	Regulator (Kohler)
42	8012-3	Regulator Mount04	$12.12	Add to Cart
43	8392	Coil Mount PlateFront	$9.24	Add to Cart
44	8392-1	Coil Mount Plate Rear	$9.42	Add to Cart
45	NS	25-hp Engine
46	7306-12	NR Temp Sender Adapter	$6.31	Add to Cart
47	7306-15	Water Temperature Sender	$42.86	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F027	1024x58 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F041	3816x134 Hex Bolt	$1.87	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F063	38 Int Star Lock Washer	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F106	3816x58 Hex Bolt	$0.94	Add to Cart
	F187	1420x112 Hex Bolt	$0.79	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F243	M6 Split Lock Washer	$0.18	Add to Cart
	F255	51618x112 Hex Bolt	$1.06	Add to Cart
	F273	M6x10 Nut	$0.22	Add to Cart
	F328	M6x10x16 Hex Bolt	$0.72	Add to Cart
