PARTS > MD MANUALS > 1998-01-20, 7000-2, Serial 29676-60191 > Engine Group MDG:

Diagram #	Part #	Description	Price	Add to Cart
1	7840	Hose Clamp 1516 214	$4.13	Add to Cart
2	7019	NR Air Intake Hose	$29.90	Add to Cart
3	7347	NR Throttle Cable Mount Brkt	$16.37	Add to Cart
4	7392	Coil Mount	$15.44	Add to Cart
5	NS	Coil (12581-68900 Kubota)
6	7442	Exhaust Pipe Shield	$29.96	Add to Cart
7	NS	Kubota Gas Engine (WG750 Kubota)
8	7840-2	Hose Clamp 14 to 58	$3.50	Add to Cart
9	7015-5	NR Hose 516x36	$15.05	Add to Cart
10	NS	Fuel Pump (12691-52031 Kubota)
11	7015-1	NR Hose 516x5	$5.50	Add to Cart
12	7020	Fuel FilterInLine	$6.11	Add to Cart
13	7015	NR Hose 14x15	$11.44	Add to Cart
14	5083	Fuel ShutOff Valve	$16.12	Add to Cart
15	5083-1	Bushing Rubber Fits 5083	$2.47	Add to Cart
16	5082	Fuel Tank Cap (Includes Item # 17)
17	5082-2	NR Fuel Cap Seal	$2.16	Add to Cart
18	8046	Fuel Tank (4.3 Gallon) (Includes Items# 14,15,16 & 17)
19	7048	Trash Guard	$11.95	Add to Cart
20	7389-1	Splash Guard	$16.50	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F233	M8x1.25x16Hex Bolt
