PARTS > MD MANUALS > 2007-09-15, 7000-10, Serial 92037-103913 > Hi-Dump Kit - Main Components:

Diagram #	Part #	Description	Price	Add to Cart
1	7613-1	Door Actuator, 7.0 / 9.5
2	7612-4	NR Door Actuator ArmRH	$11.62	Add to Cart
3	7612-3	NR Door Actuator ArmLH	$18.54	Add to Cart
4	7620-6	Cable Guide	$11.97	Add to Cart
5	7523-2	Clevis Pin WHole 14x58	$1.25	Add to Cart
6	7623-2	Power Dump Cable 95 2478	$24.62	Add to Cart
7	5552	Ball Joint 1428	$14.92	Add to Cart
8	8402-3	Backup Plate	$46.46	Add to Cart
9	7628-1	Channel AngleRH	$13.78	Add to Cart
10	8404-4	Channel AngleHiDumpLH	$26.95	Add to Cart
11	7146	13mm Ball Stud	$4.92	Add to Cart
12	7145	Gas Spring Assembly	$39.60	Add to Cart
13	7147	Spring Clip	$1.44	Add to Cart
14	5841	Retainer Washer 38x114	$1.42	Add to Cart
15	8845	Rubber Bumper 30mmOD x 40mm 51618 Female	$8.30	Add to Cart
16	8404-6	Clevis Pin 12x112	$2.71	Add to Cart
17	8402-6	Catcher Pivot Plate
18	7620-9	Roller Wheel	$8.11	Add to Cart
19	8402-2	Catcher Pivot Arm/HD	$78.87	Add to Cart
20	5830	Grease Fitting 1428	$2.47	Add to Cart
21	8404-5	Clevis Pin 12x114	$2.78	Add to Cart
22	8402-4	Upper Cylinder Mount Arm	$7.75	Add to Cart
23	8402-1	NR Catcher FrameHiDump	$589.47	Add to Cart
24	7845	Rubber Bumper 1375X63	$4.80	Add to Cart
25	8401-4	Upper Pivot Shaft	$19.27	Add to Cart
26	8201-3	Fiberglide Bearing	$13.74	Add to Cart
27	8401-5	Pivot Arm	$338.31	Add to Cart
28	8401-9	NR Decal Safety Lockout Arm	$8.88	Add to Cart
29	5683	Pivot Bearing	$10.16	Add to Cart
30	8401-1	Torsion Spring 112	$40.17	Add to Cart
31	8401-6	Spring Bushing	$11.22	Add to Cart
32	8401-3	Safety Lockout Arm	$9.17	Add to Cart
33	8401-2	Safety Lockout Spring	$7.27	Add to Cart
34	8400-3	Rear PivotLH	$91.01	Add to Cart
35	5214-10	Ball Joint 1 2 20 Hi Strength	$54.60	Add to Cart
36	8400-8	NR Decal HiDumpLexan	$7.13	Add to Cart
37	7047-5	Mount Plate	$11.42	Add to Cart
38	8430-1	Body ChuteHiDump 105	$101.77	Add to Cart
39	8400-10	NR Auxiliary Power Term Plt	$30.76	Add to Cart
40	8400-7	NR Decal Electrical Jumper Warning	$11.33	Add to Cart
41	8400-15	Switch Mount	$9.84	Add to Cart
42	8400-9	NR Decal HiDump Operation Lexan	$5.83	Add to Cart
43	8400-14	Switch Cover	$12.43	Add to Cart
44	8400-1	Bumper Hi Dump Mount	$522.12	Add to Cart
45	8400-2	Rear PivotRH	$113.93	Add to Cart
46	8402-8	Control Lift Rod	$39.36	Add to Cart
47	5214-11	Ball Joint 1 2 20LH Hi Strength	$59.45	Add to Cart
48	8403-18	Pump Guard	$32.43	Add to Cart
49	7847	Rubber Bumper 15ODx10	$6.31	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F003	1428 Hex Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F016	1213 SelfLocking Nut	$1.51	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F028	1024x34 PPHMS	$0.18	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F037	1024x58 PTH Screw	$0.18	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F039	3816x114 Hex Bolt	$1.42	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F048	12 SAE Washer	$0.50	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F052	516 Ext Star Lock Wshr	$0.18	Add to Cart
	F068	18x1 Cotter Pin	$0.18	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F106	3816x58 Hex Bolt	$0.94	Add to Cart
	F134	AN960816L Washer	$0.65	Add to Cart
	F208	51618x214 Hex Bolt	$1.54	Add to Cart
	F241	375x875x10 Washer	$0.79	Add to Cart
	F267	12x1x116 Washer	$2.26	Add to Cart
	F287	1428 Keps Nut	$0.65	Add to Cart
	F385	14x114 Roll Pin	$1.14	Add to Cart
	F395	1420x214 FHA Screw SS	$5.45	Add to Cart
	F396	1024x114 PPH Bolt	$0.66	Add to Cart
	F398	1420x2 Hex Bolt	$1.06	Add to Cart
	F399	1213x314 Hex Bolt	$4.38	Add to Cart
	F405	3816x112 FHA Screw SS	$3.24	Add to Cart
	F420	51618x114 Carriage Bolt	$1.42	Add to Cart
	F440	1220 Jam Nut RH	$8.04	Add to Cart
	F441	1220 Jam NutLeft Hand	$8.04	Add to Cart
