PARTS > MC MANUALS > 1997-02-07, 6000-2, Serial 08613-32625 > Hydrostatic Ground Drive Assemblies:

Diagram #	Part #	Description	Price	Add to Cart
1	5027	Lockout Mount
	5028-3	Trans Lockout Assembly	$32.69	Add to Cart
2	5028	Lockout Lever
3	5057	Lockout Cam	$6.50	Add to Cart
4	5847	Plastic Tip	$0.65	Add to Cart
5	6209	NR Bridge Assembly	$55.13	Add to Cart
6	6243-2	Hydro Fan CCW	$7.72	Add to Cart
7	5026	Hydrostatic Drive CW	$1,233.00	Add to Cart
8	6206	Pressure Relief Valve
9	6200-5	Gear Axle Drive Assembly (Includes Items # 8 & F259)
10	6233-1	Pinion Gear 620039	$51.06	Add to Cart
11	6234	Spacer Pinion Gear	$8.03	Add to Cart
12	6201	ORing Seal	$1.88	Add to Cart
13	6244	NR Hydro Pulley 4A	$40.13	Add to Cart
14	6243-1	Hydro Fan CW	$7.21	Add to Cart
15	5025	Hydrostatic Drive CCW	$1,233.00	Add to Cart
16	6430-10	Outboard MountLH	$21.43	Add to Cart
17	6430-2	Deck Support Arm, LH (Includes Item # 21)
18	5775-2	Hitch Pin 6	$3.24	Add to Cart
19	6430-1	Deck Support Arm, RH (Includes Item #21)
20	6430-9	Outboard MountRH	$14.10	Add to Cart
21	5830	Grease Fitting 1428	$2.47	Add to Cart
22	6840-1	Support Arm Bushing 2116	$17.60	Add to Cart
23	5025-5	Input Shaft
24	5025-8	BearingInput Shaft	$35.42	Add to Cart
25	5025-7	Snap Ring 97121	$5.08	Add to Cart
26	5025-2	SU5025 13 Seal Input Shaft	$5.48	Add to Cart
27	5022	ReservoirCasting Gasket	$5.02	Add to Cart
28	5024	Reservoir Cap Gasket	$22.92	Add to Cart
29	5023	Trans Reservoir Kit WCap	$87.51	Add to Cart
30	5023-1	Rubber Bladder	$17.89	Add to Cart
31	5025-6	ORing Plug 25090006	$10.39	Add to Cart
32	5025-3	Seal Control Shaft	$5.32	Add to Cart
	F023	1024 ESNA Nut	$0.34	Add to Cart
	F027	1024x58 PPHMS	$0.18	Add to Cart
	F036	1420x12 SBH Screw	$0.43	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F043	3816x3 Hex Bolt	$2.35	Add to Cart
	F053	716 Int Star Lock Wshr	$0.65	Add to Cart
	F063	38 Int Star Lock Washer	$0.18	Add to Cart
	F064	18x12 Woodruff Key 3	$5.45	Add to Cart
	F081	AA45D Aluminum Pop Rivet	$0.34	Add to Cart
	F160	Ext Snap Rng 669 Shaft	$0.72	Add to Cart
	F178	14x1 Fender Washer	$1.42	Add to Cart
	F194	716x114x18 Washer	$1.75	Add to Cart
	F200	71620x3 Grade 8 Bolt	$4.06	Add to Cart
	F205	51618x14 Set Screw Knurl Point	$0.94	Add to Cart
	F244	71620x34 Hex Bolt	$1.66	Add to Cart
	F259	5818x1 Hex Bolt GRD 5 Plated	$2.06	Add to Cart
