PARTS > MT MANUALS > 1997-05-22, 8000-2, Serial 21329-37479 > Instrument Panel Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	7307-2	Instrument Panel Cover	$163.07	Add to Cart
2	7307	Panel Frame
3	8960-1	NR Ignition Key 1 Set	$8.26	Add to Cart
4	8960	Ignition Switch (with Keys) (Includes Item # 3)
5	8823	Decal, Instrument Panel
6	8820	Panel Faceplate
7	7386	Panel Gasket	$11.53	Add to Cart
8	7391	Panel Box Mount Plate	$4.80	Add to Cart
9	8536	Warning Horn	$24.07	Add to Cart
10	8385	Panel Box WGraphic	$82.89	Add to Cart
11	7307-1	Shock Mount 10x25 Double Stud	$5.66	Add to Cart
12	8945	Wire Harness, Instrument Panel
	8306	NR Instrument Panel AssyT95	$312.06	Add to Cart
13	5975-1	Cable Tie 18x334	$0.34	Add to Cart
14	8990	NR Hourmeter	$23.85	Add to Cart
15	5995	Toggle Switch OffOn	$14.16	Add to Cart
16	8997	Voltmeter Gauge	$51.24	Add to Cart
17	5995-1	Wire Terminal Adapter	$2.52	Add to Cart
18	8996	Red Indicator Light (Includes Item # 20)
19	5995-2	Switch Boot	$5.26	Add to Cart
20	8996-1	Indicator Bulb (Replacement for P/N 8996)
	F004	1420 Keps Nut	$0.34	Add to Cart
	F062	8 Int Star Lock Wshr	$0.18	Add to Cart
	F228	6x58 PPHSMS SS	$0.34	Add to Cart
	F238	J Clip Instrument Panel	$0.50	Add to Cart
	F250	632x12 PPHMS	$0.18	Add to Cart
	F251	632 Keps Nut	$0.22	Add to Cart
