PARTS > MT MANUALS > 2003-01-31, 8000-7, Serial 54651-66326 > Instrument Panel Assembly - MTL:

Diagram #	Part #	Description	Price	Add to Cart
1	7307-2	Instrument Panel Cover	$163.07	Add to Cart
	8306-6	Instr Panel AssyMTL02 SenDEC Hourmeter	$534.03	Add to Cart
2	7307	Panel Frame
3	8823-4	NR DecalInst PnlMTL02Lex	$21.01	Add to Cart
4	8820-2	Panel FaceplateMTL02	$30.58	Add to Cart
5	7386	Panel Gasket	$11.53	Add to Cart
6	8960-15	Ignition Switch WKeys	$34.63	Add to Cart
7	8996-2	Red Indicator Light Assembly (Includes Items # 19 & 20)
8	7941-3	Boot Circuit Breaker	$8.90	Add to Cart
9	7941-1	Circuit Breaker (5 Amp)
10	7941-2	Circuit Breaker10AMP	$9.88	Add to Cart
11	8990-1	Hourmeter Global	$25.89	Add to Cart
12	5995	Toggle Switch OffOn	$14.16	Add to Cart
13	5995-2	Switch Boot	$5.26	Add to Cart
14	7306-3	Water Temperature Gauge
15	8997	Voltmeter Gauge	$51.24	Add to Cart
16	8945-4	Wire Harness Inst Panel MTL	$93.87	Add to Cart
17	5975-1	Cable Tie 18x334	$0.34	Add to Cart
18	8996-4	Red Indicator Lens	$10.88	Add to Cart
19	8996-3	NR Indicator Bulb 89962	$7.26	Add to Cart
20	8960-2	Ignition Key (1 Set)
21	7854	Plastic TipRed	$0.50	Add to Cart
22	7307-1	Shock Mount 10x25 Double Stud	$5.66	Add to Cart
23	7391	Panel Box Mount Plate	$4.80	Add to Cart
24	8385	Panel Box WGraphic	$82.89	Add to Cart
25	7977-1	NR Grommet 18x1116	$2.16	Add to Cart
26	7307-16	LiningPanel Box 18	$6.22	Add to Cart
27	8536	Warning Horn	$24.07	Add to Cart
28	6941	Relay Switch (30/40 Amp)
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F228	6x58 PPHSMS SS	$0.34	Add to Cart
	F238	J Clip Instrument Panel	$0.50	Add to Cart
	F250	632x12 PPHMS	$0.18	Add to Cart
	F251	632 Keps Nut	$0.22	Add to Cart
	F349	Washer 835ID 1122ODSS	$1.66	Add to Cart
