PARTS > MC MANUALS > 1997-02-07, 6000-2, Serial 08613-32625 > Light Kit:

Diagram #	Part #	Description	Price	Add to Cart
1	5989-2	Light Assy (Incandescent)	$58.82	Add to Cart
	5989-6	Sealed Beam Lamp Incndsnt	$35.38	Add to Cart
2	7834-1	Half U Wire Clip	$0.60	Add to Cart
3	5996-4	1614 GA Bullet Cntr M Insulated 59965 F	$0.79	Add to Cart
4	5996-5	1614 GA Bullet Cntr F Insulated 59964 M	$0.94	Add to Cart
5	5996-15	1210 GA Ring Term 12	$1.08	Add to Cart
6	5977-1	Grommet 18x38	$0.79	Add to Cart
7	5975-5	Wire ClipSelfMount	$1.30	Add to Cart
8	5996-1	1614 GA Butt Connector	$0.94	Add to Cart
9	5975-1	Cable Tie 18x334	$0.34	Add to Cart
10	5995	Toggle Switch OffOn	$14.16	Add to Cart
11	5995-2	Switch Boot	$5.26	Add to Cart
12	5996	14x1614 GA QDF Terminal Fully Insulated	$1.18	Add to Cart
13	7995-4	Power Lead Wire Assembly	$12.72	Add to Cart
14	7992	Mount Bracket, Lights
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F134	AN960816L Washer	$0.65	Add to Cart
