| Diagram # | Part # | Description | Price | Add to Cart |
| 1 | | Deck Caster Wheel Fork Pivot Grease Fitting | |
|
| 1 | | Deck Support Arm Socket Grease Fitting | |
|
| 2 | | Rear Wheel Bearing Grease Fitting | |
|
| 3 | | P/N 8100 Front Body Assembly (Reference) | |
|
| 4 | | Parking Brake Lever (Optional) Grease Fitting | |
|
| 5 | | Forward Speed Control Lever Pivot Grease Fitting | |
|
| 5 | | Forward Speed Control Lever Fork Grease Slide Area | |
|
| 6 | | Deck Caster Wheel Bearing Grease Fitting | |
|
| 7 | | PTO Clutch Lever Pivot Grease Fitting | |
|
| 8 | | PTO Clutch Linkage Bushing Grease Fitting | |
|
| 9 | | P/N 5470-1 Speed Control Stop (Reference) | |
|
| 10 | | FSC Actuator Rod Pivot Pins Oil | |
|
| 11 | | FSC Friction Body Pivot Grease Fitting | |
|
| 12 | | Jackshaft Assembly Pivot Oil | |
|
| 13 | | Throttle Control Cable End Oil | |
|
| 13 | | Choke Control Cable End Oil | |
|
| 14,19 | | Deck Support Arm Pivot Grease Fitting | |
|
| 15,16 | | Steering Lever Pivot Grease Fitting | |
|
| 17 | | U-Joint Shaft Assembly Grease Fitting | |
|
| 18 | | U-Joint Tube Assembly Grease Fitting | |
|
| 18 | | U-Joint Quick Connect Spline Grease Slide Area | |
|
| 20 | | P/N 8300 Chassis Frame (Reference) | |
|
