PARTS > DECKS MANUALS > 1997-07-31, 5000-5 > Lubrication Points:

Diagram #	Part #	Description	Price	Add to Cart
1		Deck Caster Wheel Fork Pivot Grease
2		Blade Drive Gearbox Oil*
3		Tee Gearbox, Deck Oil*
4		Deck Caster Wheel Bearing Grease
5		PTO Shaft Guard Hinge Oil
6		Universal Joint Shaft Assembly Grease**
7		Pivot Assembly, Tilt-Up Deck Grease
8		Deck Support Arm Socket Grease
9		Deck Roller Wheel Oil
10		Discharge Chute Hinge (Used only on GHS Deck Assemblies) Oil
11		Discharge Shield Hinge (Not Shown, Used only on SD Deck Assemblies) Oil
1		Deck Caster Wheel Fork Pivot Grease
2		Blade Drive Gearbox Oil*
3		Tee Gearbox, Deck Oil*
4		Deck Caster Wheel Bearing Grease
6		Universal Joint Shaft Assembly Grease**
8		Deck Support Arm Socket Grease
9		Deck Roller Wheel (Not Shown, Used on 36?, 42? and 48? Assemblies) Oil
10		Discharge Chute Hinge (Not Shown, Used only on GHS Deck Assemblies) Oil
11		Discharge Shield Hinge (Used only on SD Deck Assemblies) Oil
12		Anti-Scalp Roller (Used on 52?, 54? and 62? Decks) Oil
4		Deck Caster Wheel Bearing Grease
6		Universal Joint Shaft Assembly Grease**
8		Deck Support Arm Socket Grease
11		Discharge Shield Hinge (Used only on SD Deck Assemblies) Oil
12		Anti-Scalp Roller (Used on 52?, 54? and 62? Decks) Oil
13		Blade Spindle Grease
14		Right Angle Gearbox Oil***
15		Dolly Wheel Retract Lever and Linkage Oil
16		Dolly Wheel Pivot Grease
