PARTS > DECKS MANUALS > 2006-07-01, 5000-17 > Lubrication Points:

Diagram #	Part #	Description	Price	Add to Cart
1		Deck Caster Wheel Fork Pivot Grease
2		Blade Drive Gearbox Oil*
3		Tee Gearbox, Deck Oil*
4		Deck Caster Wheel Bearing Grease
5		Universal Joint Shaft Assembly Grease**
6		Pivot Assembly, Tilt-Up Deck Grease
7		Deck Support Arm Socket Grease
1		Deck Caster Wheel Fork Pivot Grease
4		Deck Caster Wheel Bearing Grease
5		Universal Joint Shaft Assembly Grease**
6		Pivot Assembly, Tilt-Up Deck Grease
7		Deck Support Arm Socket Grease
8		Idler Arm, 2-Hole Grease
9		Blade Spindle Grease
10		Right Angle Gearbox Oil***
11		Dolly Wheel Retract Lever and Linkage Oil
12		Dolly Wheel Pivot Grease
1		Deck Caster Wheel Fork Pivot Grease
2		Blade Drive Gearbox Oil*
3		Tee Gearbox, Deck Oil*
4		Deck Caster Wheel Bearing Grease
5		Universal Joint Shaft Assembly Grease**
6		Pivot Assembly, Tilt-Up Deck Grease
7		Deck Support Arm Socket Grease
14		Rear Deck Caster Wheel Axle Grease
