| Diagram # | Part # | Description | Price | Add to Cart |
| 1 | | Steering Lever Pivot Grease | |
|
| 2 | | Body Hinge Point Oil | |
|
| 3 | | Deck-to-PTO Coupling (Grease Spline Slide Area) Grease | |
|
| 4 | | FSC Actuator Rod Pivot Pins Oil | |
|
| 5 | | (FSC) Friction Body Pivot Grease | |
|
| 6 | | FSC Lever Pivot Grease | |
|
| 7 | | FSC Lever Fork (Grease Slide Area) Grease | |
|
| 8 | | Deck Support Arm Pivot Grease | |
|
| 9 | | Universal Joint Tube Assembly Grease* | |
|
| 10 | | Parking Brake Lever Grease | |
|
| 11 | | Universal Joint Quick Connect Spline (Grease Slide Area) Grease | |
|
| 12 | | Gear Axle Oil** | |
|
| 13 | | PTO Clutch Lever Pivot Grease | |
|
| 14 | | Brake Actuator Rod and Brake Band Pivot Pins (Clevis) Oil | |
|
| 15 | | Clutch Actuator Push Rod Grease | |
|
| 16 | | Belt Tightener Pivot, Ground Drive Grease | |
|
| 17 | | Throttle Control Cable Ends Oil | |
|
| 18 | | Cold Start Lever Grease | |
|
| 19 | | Catcher Hinge Point Oil | |
|
| 20 | | Rear Wheel Bearings Grease | |
|
| 21 | | Engine Dipstick / Oil Filler Oil** | |
|
| 22 | | PTO Gearbox Dipstick Oil** | |
|
| 23 | | Belt Tightener Pivot, Blower Drive (GHS Model Only) Grease | |
|
| 24 | | Hydrostatic Drive Oil** | |
|
| 25 | | Throttle Control Pivot Oil | |
|
