PARTS > MR MANUALS > 2019-08-28, 1000, Serial 158429-160823 > Main Component Power Transmission:

Diagram #	Part #	Description	Price	Add to Cart
1	1410	ClutchMR	$138.39	Add to Cart
2	1410-2	Clutch Step Washer	$13.90	Add to Cart
3	1010-2	Spacer (.750 x .375 x .625)
4	1300-3	Twin Idler MountLH	$27.98	Add to Cart
5	5247-2	VGroove Idler 4	$31.77	Add to Cart
6	5245-2	Idler Pulley 234	$21.01	Add to Cart
7	1300-4	Twin Idler MountRH	$17.12	Add to Cart
8	1410-1	Clutch Stop	$11.43	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F040	3816x112 Hex Bolt	$1.54	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F438	51618x234 Hex Bolt	$0.50	Add to Cart
	F626	71620x212 Hex Bolt GR8	$4.19	Add to Cart
