PARTS > MB MANUALS > 2026-04-01, 4000-50, Serial 196174-AND ON > Parking Brake Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	4401-5	Brake Pivot Bracket
2	7201-11	Inner Race 1938	$15.32	Add to Cart
3	5830	Grease Fitting 1428	$2.47	Add to Cart
4	4406-52	Parking Brake Lever (Includes
5	7406-1	Handle GripRed	$3.02	Add to Cart
6	8655-4	Clevis Pin 516x34	$1.06	Add to Cart
7	5281-2	Clevis Pin 516x78	$1.32	Add to Cart
8	2280	Clevis 38	$24.27	Add to Cart
9	4401-7	Parking Brake Pivot	$8.29	Add to Cart
10	4407-6	Parking Brake Actuator
11	4407-27	Parking Brake Bolt Stabilizer
12	5665-1	Compression Sprg 212	$4.68	Add to Cart
13	5463	Steering Lever Actuator	$11.36	Add to Cart
14	4407	Parking Brake Link	$13.90	Add to Cart
15	5222	Ext Spring 12x314	$6.82	Add to Cart
16	4401-9	Parking Brake Mount	$10.27	Add to Cart
17	4401	Parking Brake Actuator Push
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F111	18x34 Cotter Pin	$0.18	Add to Cart
	F182	14x58x18 Washer	$1.20	Add to Cart
	F183	312x700x074 Washer	$0.58	Add to Cart
	F336	3816 Jam Nut	$0.34	Add to Cart
	F350	1420 LP Nylock	$0.65	Add to Cart
	F369	51618X412 Hex Bolt	$2.16	Add to Cart
	F438	51618x234 Hex Bolt	$0.50	Add to Cart
	F551	51618 Flange Top Lock Nut	$1.06	Add to Cart
	F582	Washer 516x78x125	$1.99	Add to Cart
